High Pressure Water Jet Cutting Sand Clearing Machine for Effective Sand Cleaning

Product Description

Introducing our company's groundbreaking third-generation water cutting machine sand-water separation system, specially engineered for the efficient removal of waste sand using a water knife. This innovative equipment overcomes numerous challenges associated with traditional waste sand removal methods, offering unparalleled advantages and setting a new benchmark in sand cleaning technology. It stands out as the most effective, convenient, simple, and practical water knife sand-water separation system available both domestically and internationally.
Our mission is to save your valuable time and generate greater benefits for you! This device can operate concurrently with the water knife; by simply placing the sand suction head into the water tank, sand cleaning can proceed seamlessly. The sand cleaning process does not interrupt the normal operation of the water knife, completely eliminating the need for shutdowns, water discharge, and re-filling of the tank that traditional sand cleaning methods require. This time-saving feature ensures continuous, efficient operation. The water knife sand removal system is an indispensable asset for your operational setup.
Electric Sand Cleaning Equipment Specifications
Model Specification: JSJ-3Series

maximum flow (L/min)	378.5	working medium	Water sand	Voltage (V)	380
Maximum lift (m)	84	Working environment range	5-60ºC	Suction sand (m³/h)	0.6
Maximum suction (m)	5.48	Conveying medium range	-20ºC-150ºC	Sand discharge speed	52 RPM
outlet pressure (kg)	8.4	Recommended lubricating oil	ISO VG32	displacement	Can /10 minutes
caliber (mm)	50	type of drive	electric	Structure	Vertical cylinder
Total Power(KW)	7.5(3*2+1.5)	Tank thickness (mm)	6	external dimension	Φ 600*2300
particle diameter (mm)	3.5	Floor area (m ²)	1	Gross weight (KG)	310
Power consumption (kw/h)	1.95(Per can)	place of origin	Huaian
