Dog Cat Food Pellet Fertilizer Making Machine Rotary Fish Feed Press Machine

Product Description

Dog Cat Food Pellet Fertilizer Making Machine Rotary Fish Feed Press Machine Product Description
Principle of the equipment:
The transmission mechanism is composed of triangle belt, worm gear and three-payment spur gear transmission. The equipment is equipped with a set of relative rotating knives through the gears, and the slightly moist powder is crushed into granules through the holes of the stainless steel sieve barrel, and the output is 4 times higher than that of the swing type granulator, and the granule yield can reach more than 95%.
The rotary granulator is suitable for granulation of chemical, food,Chinese medicine punch, foodstuff, solid beverage, chicken essence and other viscosity materials.
This machine is suitable for food, chemical, pesticide, fertilizer, light industry and other industries. It can also be used to crush the dry powder which has been pressed into lump form to the required size of particles.
The whole machine is made of stainless steel, beautiful appearance, reasonable structure, high granulation rate, beautiful particles, automatic discharge, to avoid the breakage of particles caused by manual discharge, and suitable for flowing operation.
Using the action of a set of inverted rotary grinder, it is extruded into granules through the stainless steel sieve. It is especially used in the food industry to produce chicken essence in the chicken essence production line. MSG and solid beverage.
And according to the user's need to choose different apertures of the sieve barrel, and material contact parts are made of stainless steel material, can ensure the original color of the material and not deteriorate.
Product Parameters

Model	XZ-100	XZ-250	XZ-300
Diameter of sieve cylinder	100mm	250mm	300mm
Aperture (according to requirements)	0.7-8mm
Rotation speed of grinder	60rpm/min
Capacity	5-30kg/h	50-200kg/h	80-270kg/h
Motor power	0.75KW	5.5KW	7.5KW
Rated rotation speed	1440 rpm/min
Weight	65KG	313KG	350KG
Dimension(mm)	550*500*550	900*600*1000	950*630*1140
