Energy Saving Outdoor Waterproof Full Color LED Display 3.91mm

Product Description

Product Description
Series outdoor LED products have the characteristics of high contrast, high refresh, wide viewing Angle, high reliability of fault detection, pre/post maintenance, etc., the picture is clear and bright under direct sunlight, and the display effect is natural and real, which is very suitable for outdoor advertising media.
Simple appearance, light and thin box design, stable and reliable IP66 high protection grade, full waterproof module, sealed design, wireless plug, adapt to a variety of harsh environments All aluminum chassis, engine structure design, increased contact area with air, high heat dissipation efficiency 3840Hz ultra-high refresh frequency, the screen display is delicate and smooth High brightness, high contrast, excellent visual perception Support pre/post maintenance, adapt to all installation environments, easy maintenance It can be stitched in any direction and size, and the picture is uniform without stitching

Model	LED Display Terminal	EV100039
Module Composition	Pixel Composition	1R1G1B
	LED Packaging	SMD1921
	Pixel Pitch (mm)	3.91
	Module Resolution (W×H)	128×64
	Module Size (W×H) (mm)	500×250
Cabinet	Unit Size (W×H×D) (mm)	500×500×80/500×750×80/500×1000×80
	Unit Weight (kg)	34 kg /m2
	Unit Flatness (mm)	≥98%
	Maintenance Method	Front maintenance
	Protection Level	IP66
	Cabinet Material	Aluminum profile
	Flatness	≤0.1mm
Optical Parameters	Pixel Correction	Support brightness and chroma point by point correction
	Brightness (cd/m2)	Standard 4500 (Customizable to 11000)
	Color Temperature (K)	9000 (adjustable from 2000K to 12000K)
	Visual Angle	160° horizontal / 120° vertical
	Brightness Uniformity	≥98%
	Color Uniformity	Within ±0.003Cx, Cy
	Maximum Contrast	5000:1
Electrical Parameters	Peak Power Consumption (W/m2)	≤750
	Average Power Consumption (W/m2)	≤300
	Power Supply Requirement	110-220V/200-240V
Processing Performance	Driving Method	Constant current drive
	Frame Change Frequency	50/60Hz
	Refresh Rate (Hz)	1920/3840
	Processing Depth (Bits)	14-16
	Brightness Control	Manual/automatic/programmed
Usage Parameters	Typical Value Of Life (H)	≥100000
	Operating Temperature/Humidity Range	-20ºC -50 ºC / 10%-90%RH (non-condensing)
	Storage Temperature/Humidity Range	-40ºC -80 ºC / 10%-90%RH (non-condensing)
	Installation Method	Outdoor fastening

Note: The above parameters are typical values of the product. Different batches of products may vary. The actual parameters of the product are subject to the factory inspection report. The product will be continuously optimized and iterated during the production process, and the product specification sheet will be adjusted at any time. Consult regional distributors before purchasing. For customized products, the specification sheet needs to be reissued. Company Profile
