High quality heavy duty vertical milling machine X5032 X5032B
| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X5032 X5032B
Structure
Lifts
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Overall Welding Tooth
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Table Size
320X1250mm
Long Travel(mm)
700mm
Cross Travel(mm)
255mm
Vertical Travel(mm)
325mm
Motor
7.5kw
Transport Package
Plywood Case
Specification
3200kgs
Trademark
HOTON
Origin
China
HS Code
8459590000
Production Capacity
10 PCS/Month
Product Description
VERTICAL MILLING MACHINE FEATURES:
Model X5032 Vertical Knee-type Milling Machine, has extra travel in longitudinal, operating control adopts a cantilever panel. It is suit for milling flat, inclined face, angular surface, slots by employing disc cutters, angular cutters. When mounted with the index, the machine will be able to perform milling operations in gears, cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ± 45° . Spindle quill can be moved in vertical. The longitudinal, cross and vertical movements of the table can both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.
SPECIFICATIONS:
| SPECIFICATION | UNIT | X5032 | X5032B |
| Table size | mm | 320X1325 | 320X1600 |
| T-slots (NO./Width /Pitch) | 3/18/70 | 3/18/70 | |
| Longitudinal travel (manual/auto) | mm | 700/680 | 900/880 |
| Cross travel (manual/auto) | mm | 255/240 | 255/240 |
| Vertical travel (manual/auto) | mm | 350/330 | 350/330 |
| Rapid feed speed | mm/min | 2300/1540/770 | 2300/1540/770 |
| Spindle bore | mm | 29 | 29 |
| Spindle taper | 7:24 ISO50 | 7:24 ISO50 | |
| Spindle speed range | r/min | 30~1500 | 30~1500 |
| Spindle speed step | steps | 18 | 18 |
| Spindle travel | mm | 70 | 70 |
| Max.swivel angle of vertical milling head | ±45° | ±45° | |
| Distance between spindle nose and table surface | mm | 60-410 | 60-410 |
| Distance between spindle axis and column guide way | mm | 350 | 350 |
| Feed motor power | kw | 2.2 | 2.2 |
| Main motor Power | kw | 7.5 | 7.5 |
| Overall dimensions(L×W×H) | mm | 2294×1770 ×1904 | 2294×1770 ×1904 |
| Net weight | kg | 2900/3200 | 2900/3200 |
| Contact Us: |
| Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
