High Quality Automatic Fire-Proof Roller Shutter Door Motor AC 1000 Kgs -3p

Product Description

We are one professional supplier of electric rolling door motor.
We developed and supply for our customers roller shutter door motor (300KG-2000KG),and AC-DC rolling door motor,fire-proof rolling door motor and accessories. Our products are made of aluminum alloy casing with a light weight, low noise, long life, power strong, safe, durable quality, anti-roll over.
Most of them are widely used in shopping malls, garages, hotels, factories and so on.
In addition, we also provide many extra services for customers.
Customize Brand, Colour and Packing: We offer customized logo services, allowing you to brand your product with your company's name or logo, perfect for businesses looking to re-sell our products as their own.
Reliable Performance: With a 1-year warranty and free spare parts, you can trust our product to provide reliable performance for years to come. Our customer support team is always available to address any concerns you may have.
Low Noise Operation: Our motor winding is made from high-quality copper/aluminum, ensuring a low noise operation that won't disturb you or your neighbors. • Multi-Phase Compatibility: This motor is compatible with both single and three-phase power sources, making it a versatile option for various applications.

Electric Rolling Door Motor Technical Parameters
Type	Rated Power (W)	Rated Lifting Strength(KG)	Maximum Output Torque(N.m)	Output Speed (r/min)	Maximum Lift Height (M)	Use Chain No	Continued Work Time
600 KG-1P	200	350	168	4.8	6	10A	5
600 KG-1P	250	450	343	4.8	6	10A	5
600 KG-1P	300	500	412	4.8	6	10A	5
600 KG-1P	370	600	412	4.8	6	10A	5
800 KG-1P	550	800	647	3.94	9	10A	8
1000 KG-1P/3P	550	1000	809	3.75	9	12A	13
1300 KG-1P/3P	600	1300	1401	4.4	9	12A	13
1500 KG-1P/3P	800	1500	1617	5.2	9	16A	13
2000 KG-3P	1500	2000	2450	6	13	16A	13
Fire-proof Motor Technical Parameters
Type	Rated Power (W)	Rated Lifting Strength(KG)	Maximum Output Torque(N.m)	Output Speed (r/min)	Maximum Lift Height (M)	Use Chain No	Continued Work Time
F-600 KG-3P	250	600	412	4.8	6	10A	5
F-800 KG-3P	300	800	590	3.94	9	10A	5
F-1000 KG-3P	300	1000	617	3.75	9	12A	5
F-1500 KG-3P	800	1500	1617	5.2	9	12A	5
F-2000 KG-3P	1500	2000	2450	3.6	16	16A	13
