USB3.0 Cable for Internal Wiring of Consumer Electronic Product.

Product Description

Application: Internal wiring of consumer electronic product. Products are used in interconnection between computer and office devices, such as digital cameral, Media player, mobile phone, external hard drivers and electronics. Application standard: UL444 UL13,UL1581&USB3.0,IEC60754 Product character: 10 times as fast as transmission rate of USB2.0 cable, it's up to 4.8G and meet to read and write at same time. Save more space and have backward compatibility Constructure: Stranded silver -plated copper conductor, 28-20AWG Foamed PE insulation AL-mylar shielding, tinned copper braiding PVC, PU or FRPE jacket Technical parameter: Rated temperature :80ºC Rated Voltage:30V
Remark:Similar specifications can be designed according to customer requirements.

Product number	CORES	Conductor		Insulation		Shield			Jacket
		Material	NO./mm	Material	Nom. Dia. mm	Material	Braid	Nom. Dia. mm	Material	Nom. Dia. mm
HT-3.0USB001	6C*28AWG	SPTC	0.38	FRPE	0.90	A-Mylar	TC	5.90	PVC	7.00
HT-3.0USB002	6C*28AWG	SPTC	0.38	FRPE	0.90	A-Mylar	TC	5.90	PU	7.00
HT-3.0USB003	6C*28AWG	SPTC	0.38	FRPE	0.90	A-Mylar	TC	5.90	FRPE	7.00

Remark: SPTC----Standard silver plated copper
TC--------Tinned copper wires

Mechanical specifications		Electrical specifications			Attenuation,Maximum@ 20ºC
		Impedance		90+/-7Ω	Frequency, MHz	dB/ft	dB/m
Min. Bend Radius	7*OD	Capacitance		42pF/m	625	0.27	0.87
Product Weight	51.5kg/kg	Capacitance		4.25pF/m	1250	0.38	1.25
Rated temperature	80ºC	Next	0.1~2.5GHz	<100ps/5m	1562	0.43	1.41
			2.5~3.0GHz	<400ps/5m	2500	0.55	1.81
			3.0~7.5GHz	<-55dB@1.25GHz	3125	0.80	2.63

Company Profiles:
Founded in 2004 with 16 years of development, we Hwatek established our new plant Nantong Hwatek Wires & Cable Co., Ltd in 2020. Located in Nantong City, Jiangsu Province, our new plant covers 34,000 square meters with 100 million investment.
We are dedicating to R&D and produce various wires and cables like industrial control, communication instruments, medical control, green energy EV and special wires and cables etc. OEM & ODM is also available.
Our Nantong Plant has passed ISO9001, ISO14001, IATF16949, ISO13485 quality system certification. All the ranges of our wires and cables are CCC, UL, CUL, CE, CSA ,TUV,DEKRA,IEC,CQC or ETL qualified. With the company principle 'Profession, Integrity, Eco Friendly and Win-win', we are equipped with a comprehensive sales network to serve customers in various fields around the world.
Frequently Asked Question:
1.Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2.Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3.Q:Can we get samples before ordering?
A:Yes, we are willing to arrange samples for you.
4.Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5.Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
