Customized Acceptable Sinsitive Single or Three Phase Voltage Regulator for Precise Machinery, Textile Medica Laser Woodworking and Aviation Equipment

Product Description

Technical parameters

(1) Product model:	Z N W-
(2) Rated capacity:	60-3000KVA
(3) Phase:	Three phase / single phase
(4) Input voltage regulation range:	220V 380V 400V Other:	±15% ±20% ±25% ±30% Other:
(5)Input voltage:	220V 380V 400V Other::
(6)Voltage regulation rate:	±2%(±1%,±1.5%,±2%,±2.5%,....±5%
(7)Efficiency:	>=98%
(8)Frequency:	50Hz /60Hz
(9)Response time:	<40ms
(10)Insulation class:	E
(11)Insulation resistance:	Insulation resistance of the whole machine to ground >5MΩ
(12)Dielectric strength:	2500VAC/1min no arcing discharge, no breakdown
(13)Output waveform:	Output waveform is distortion free, no harmonic increment
(14)Instantaneous overload capability:	2 times rated current
(15)Display method:	LED/LCD display
(16)Way of working:	Long-term continuous operation
(17)Protective function:	Overload, overvoltage, undervoltage, phase loss, overtemperature
(18)Heat dissipation method:	AN/AF

Introduction of products.Dry type transformer has developed and further improved in the aspects of raw materials and technology by Po MING POWER,Compared to others in the industry, our products show advantages as below:
Lower noise,
Lower wear and tear,
Lower voltage drop,
Higher efficiency
More stable operation.
This series of products are suitable for the circuits with AC 50/60Hz and voltage less than 660V.
This transformer is widely used for precise machinery,multi-axial automatic lathe,spring manufacturing machine,injection machine,mechanical and electronic equipment,medical equipment,rectifier,lighting etc.
Application.The product can be used for Precise Machinery Equipment, Textile Equipment, Medica Equipment, Laser Equipment, Woodworking Equipment, and Aviation Equipment.
Package:
1) Carton Package;
2) Neutral Non-fumigation Wooden Package;
3) Customized Package.
