Factory Price Intel Core I7 10510u Processor Mini PC with SIM Card Slot

Product Description

Product Description
Fanless intel celeron/I3/I5/I7 8th/10th/11th Gen mini pc
Optional Intel Celeron J4125/J6412 and Intel 8th/10th/11th Gen core i3/i5/i7 CPU.
- 2 x Intel i225V 2.5G LAN and 2 x RS232/RS422/RS485 COM+4 x Expanded RS232 COM.
- Full Aluminum Alloy Black color shell for heat dissipation, Exquisite production craft on outside design.
- Fanless system without cooling fan, fit for industrial grade field, work as long as 24 hours.
- Installation: support desktop and wall-mounted, customized Din rail. Product Parameters
Model: JFTCJ4125IL CPU: Onboard 14nm Gemini Lake Intel Celeron J4125 2.0GHz Quad Cores Four Threads Max 2.7GHz(Turbo boost Technology) TDP 10W 4MB Cache Intel® UHD Graphics 600. Model: JFTCJ6412IL
CPU: Onboard 10nm Elkhart Lake Intel Celeron J6412 2.0GHz Quad Cores Four Threads Max 2.6GHz(Turbo boost Technology) TDP 10W 1.5MB Cache Intel® UHD Graphics.
Model:JFTC8260UIL
CPU: Onboard 8th Gen Whiskey Lake 14nm CPU Intel Core i5-8260U Four Cores Eight Threads 1.6GHz up to 3.9GHz(Turbo boost Technology) 6MB cache TDP 15W Intel® UHD Graphics 620.
Model: JFTC8365UIL
CPU: Onboard Intel Whiskey Lake 14nm CPU Intel Core i5-8365U 1.6GHz Max 4.1GHz (Turbo boost Technology) Four Cores Eight Threads 6MB cache TDP 15W Intel® UHD Graphics.
Model: JFTC8565UIL
CPU: Onboard Intel Whiskey Lake 14nm CPU Intel Core i7-8565U 1.8GHz Max 4.6GHz (Turbo boost Technology) Four Cores Eight Threads 8MB cache TDP 15W Intel® UHD Graphics.
Model: JFTC10210UIL
CPU: Onboard Intel Comet Lake Refresh Intel Core i5-10210U Processor, 6M Cache, 1.6GHz up to 4.20GHz (Turbo boost Technology) Two Cores Six Threads TDP 15W Intel® UHD Graphics
Model: JFTC10510UIL
CPU: Onboard Intel Comet Lake Refresh Intel Core i7-10510U Processor, 8M Cache, 1.8GHz up to 4.9GHz (Turbo boost Technology) 4 Cores 8 Threads TDP 15W Intel® UHD Graphics.
Model: JFTC1135G7IL
CPU: Onboard 11th Gen 10nm CPU Comet Lake Intel Core i5-1135G7 Four cores Eight threads 2.4GHz up to 4.2GHz 6MB cache TDP 12W Intel Iris Xe Graphics.
Model: JFTC1165G7IL
CPU: Onboard 11th Gen 10nm CPU Comet Lake Intel Core i7-1165G7 4 cores 8 threads 2.8GHz up to 4.7GHz 12MB cache TDP 12W Intel Iris Xe Graphics.

Basic Information
CPU	Intel Celeron J4125 J6412 Intel Core i3 i5 i7
TDP	Refer to the CPUS
Chipset	SOC
Memory Specifications
Memory Types	J4125/J6412: 1 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB 8th/10th/11th: 2 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB/64GB
OS	Windows 10/Windows 11, WES 7/10, Linux
PXE	YES
Audio	Intel high definition audio controller
Network	2 x Intel(R) i225V Gigabit Network Connection 10/100Mbps/1000Mbps BaseT LAN
Processor Graphics	Refer to the cpus
Wi-Fi:
Module	1 x M.2 2230 slot for Wi-Fi & Bluetooth module 1 x M.2 3042/3052 slot for 3G/4G/5G/Wi-Fi module
Antenna	5 x inner RF cables and 2 x external antennas
Input/output port
Switch	1 x Power On/Off Switch
Power	1 x 4pin phoenix terminal power supply input, support 9~36V
EXT IO	1 x Integrated 4-way 3-wire COM, 10-way GPIO, 1 x Remote Switch
USB	J4125/J6412: 4 x USB3.0, 2 x USB2.0, 8th/10th/11th: 2 x USB3.0, 4 x USB2.0
Display	1 x HDMI 1.4
LAN	2 x RJ45 Intel 2.5G LAN(support four extended network ports)
COM	2 x RS232/RS422/RS485 COM, 4 x Expanded RS232 COM
ATX	1 x ATX
Audio	1 x Audio
SIM	1 x embedded SIM card slot onboard
Storage
MSATA	1 x M.2 slot for SATA 2242/2260/2280 SSD 1 x M.2 slot for SATA/NVME 2280 SSD
SATA	1 x SATA3.0 slot for SATA HDD or SSD
Product Dimension & Details:
Case Material	Black color aluminum alloy(any customized color for bulk order)
Dimension	PC size 300*155*50mm
	Package size 370*230*150 mm
Weight	Net 1.8kg, Gross 2kg
Mounting	4 mounting holes one the case baseplate
Functions	AWAL, Wake On LAN, RTC, Watchdog
Cooling Mode	Fanless
Package Content
Standard	1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag,
Optional	5xWi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xLong Screws Bag, 1xExtension Interface
Power and Working Environment
Input	100-240V AC/50-60Hz
Output	9V~36V
Operating Temperature	-20°C/+60°C
Storage Temperature	-30°C/+70°C
Relative Humidity	10%~90% @30°C(non-condensing)

Detailed Photos
FAQ Q: What is the expected lifespan or durability of the product? A: Our product has an expected lifespan of above 5 years and is designed to withstand heavy use in industrial environments.
2. Q: What is your company's experience and reputation in the industry?
A: Our company has been in business for more than 13 years and has a reputation for delivering high-quality products and excellent customer service. We have worked with numerous clients in various industries.
3. Q: What is your company's policy on returns and refunds?
A: We have a flexible returns and refunds policy that allows customers to return products within 15 days of purchase for a full refund or exchange. We also offer warranties on our products to ensure customer satisfaction.
4. Q: Are there any certifications or standards that the product meets?
A: Yes, our product meets several industry certifications and standards, including CE/FCC/ROHS .

5 . Q : Are the prices and specifications final?
A: No, because every customer have different requirements.Meanwhile We will update our products gradually .Above specifications and prices are only for reference .The final specifications and prices are based on the actual products. Please confirm all with us before making an order !
