Ornamental Floating Sinking Fish Food Extruder Line Aquatic Feed Make Machine

Product Description

Ornamental farm catfish carps shrimp fish feed production line floating food pellet machine
Sweet Fresh Water Tropical Ornamental Fish Feed Machine Koi Golden Fish Food Production Line
Puffing Machine For Fish Feed Aquarium Farm Shrimp Food Sinking Floating Pellet Production Line Equipment Machinery
Ornamental floating sinking fish food extruder line aquatic feed make machine
Ornamental floating sinking fish food extruder line aquatic feed make machine Product Description
150-5000 kg per hour Ornamental floating sinking fish food extruder line aquatic feed make machine is specicially designed based on customers' workshop space, power, steam resource, fish feed type, pellets sizes requirement, automation degree requirement, ingredients, etc.
We can provide automatic raw materials mixing, grinding, distribution system for the fish feed production line. User also can buy flour form ingredients from local market.
Just tell us the conditions and requirements, we well provide solution for you. Welcome to send inquiry to us!

Product Parameters
A. Dry extrusion lines for feed:
(small and middle scales investors favorite models)
Mixer → Screw conveyor→dry extrusion machine(extruder)→air conveyor→ dryer(electric/gas/diesel)→flavoring machine→ cooling machine→ packing machine

Model	JY-65	JY-70	JY-85	JY-95	JY-120
Capacity(kg/h)	150 kg/h	250kg/h	400-500 kg/h	800-1500kg/h	1500-2000 kg/h
Power	80 kw	105 kw	205kw	185 kw	250kw
Dimension(L*W*H)	17*2.5*2.8 m	20*2.5*3 m	28*3.5*3.5 m	40*5.5*6.5 m	48*6.5*8.5 m

B. Wet extrusion lines for aquatic and aquarium feed
(Wet extrusion lines, investors should install steam generators or boilers):
Raw materials processing system → Pre-conditioning system → High Capacity Fish Feed Extruder → Fish Feed Steam Drying Machine→(Hoister with Flavor→ Oil Sprayer→ Roller) optional → Storage bin → Packing system

Item	JY-0.5T/h	JY-0.8-1 T/h	JY-1-1.5 T/h	JY-2-3 T/h	JY-3-5 T/h
Installed Power	80kw	100kw	130kw	150kw	200kw
Production Capacity	400-500 kg/h	800 - 1000 kg/h	1000-1500kg/h	2000-300kg/h	3000-5000kg/h
Dimension	17*2*2.5m	22*2*2.5 m	30*3*3.5m	42*5*6.0 m	45*5*6.0 m

Power requirement:
Three phases: we can make Aquarium Shrimp Fish Pellet Food Extruder Floating Sinking Fish Feed Machine according to customers' Local voltage according to different countries Company Profile
Shandong Joyang Machinery Co., Ltd.is a professional supplier of Ornamental floating sinking fish food extruder line aquatic feed make machine. We are located in Jinan, the capital of Shandong Province. Our company is full of staff with many years of experience in supplying the food process machines.
Our machines are customized machines, our professional engineers will supply the most suitable solution to different customers to meet their various demands.
We have developed the "JY" series 0.5-5 ton per hour Fish Feed Extruder Production Line Floating Food Machine Plant Line in various specifications in accordance with CE standards.

Our service
We will provide the most thoughtful services for our clients: Before sale services:
1.Provide the free consultation of the equipment
2.Provide the standard device and the flow chart
3. According to the clients' special requirement, offering the reasonable plan and free design helping to select the equipment.
Services during the sales:
1.Help client design the factory and offering professional advice, free engineering drawing for the factory layout.
2.Welcome to visit our factory or the domestic clients' factory.
3.Inspect the machine before leaving the factory.
After sale services:
1. Oversea install and debug the equipment.
2. Train the first-line operator.
3. Provide the basic formula
4. Operation/ Service/ Maintenance Manual: Provided In English.
