X6330W vertical and horizontal turret milling machine
| US$3,300.00-3,600.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X6330W
Structure
Ram
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Table Size
1500*330mm
Long Travel(mm)
1000mm
Cross Travel(mm)
350mm
Vertical Travel(mm)
360mm
Motor
5 Kw
Transport Package
Plywood Case
Specification
1980kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459590000
Production Capacity
10 PCS/Month
Product Description
Main Feature:
Good stability with rectangular guide rails
Work table and guide rail by super audio quenching
Table X Y Z are gear drive automatic feed
| Specifications | unit | X6330W | |
| Table size | mm | 1500*330 | |
| Table travel (X/Y/Z) | mm | 1000*350*360 | |
| Rapid speed of table (X/Y/Z) | Mm/min | 1000*1000*400 | |
| Spindle taper | Vertical axis | -- | NT40 NT40 |
| Horizontal axis | |||
| Table feed(X/Y/Z) | mm/min | 1000/1000/400 | |
| Distance between horizontal nose and table surface | mm | 0-360 | |
| Distance between spindle axis and ram surface | mm | 300 | |
| Spindle speed range(50HZ) | Vertical axis | r/min | 50-3750 (Variable) |
| Vertical axis | 66-4540 (16 grade speeds) | ||
| Horizontal axis | 40-1300 (12 grade speeds) | ||
| T - slot (NO./width/pitch) | mm | 3/18/85 | |
| Arm travel | mm | 500 | |
| Main motor power | Vertical axis | HP | 5kw |
| Horizontal axis | 4kw | ||
| Overall size(L*W*H) | mm | 2400*1700*2350 | |
| Net weight | kg | 1980 | |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
