35byg 0.9 Degrees 1.8 Degrees Stepper Motor

Product Description

35BYG 0.9 degrees 1.8 degrees High Quality Stepper Motor
Stepper motor parameters
35BYG 0.9°

Model	Number of phase	Current (A)	Lmductance(Ω)	Inductance(mH)	Holding Tnertia(Nm)	Rotor Inertia(g-cm²)	Detent Torque(mNm)	Weight(kg)	Length(mm)
35BYG28-S4040	2	0.4	23	25	0.1	14	10	0.16	28
35BYG28-S4060	2	0.6	6.6	6	0.85
35BYG28-S6040	4	0.4	23	13	0.07
35BYG28-S6060	4	0.6	6.6	2.7	0.07

35BYG 1.8°

Model	Number of phase	Current (A)	Lmductance(Ω)	Inductance(mH)	Holding Tnertia(Nm)	Rotor Inertia(g-cm²)	Detent Torque(mNm)	Weight(kg)	Length(mm)
35BYG20-4040	2	0.4	25	18.5	0.05	8	6	0.1	21
35BYG26-6080	2	0.8	4.8	4.3	0.08	10	8	0.12	27
35BYG28-4050	2	0.5	20	18	0.1	10	8	0.14	28
35BYG28-S4075	2	0.75	4.3	4.3	0.08
35BYG34-S4085	2	0.85	5.5	5	0.14	20	15	0.22	35
35BYG34-S6120	4	1.2	2.7	1.4	0.12
35BYG45-S4100	2	1	3.6	4.3	0.25	25	20	0.3	45

Note:
If you need customized stepper motors, pls freely contact us. We will provide you with a suitable motor solution and price soon.
FAQs:
1 Q: What's your MOQ ?
A: 1unit is acceptable.
2 Q: What about your warranty?
A: 1-2 years.
3 Q: Do you provide OEM service with customer-logo?
A: Yes, we could do OEM orders.
4 Q: How about your payment terms ?
A: TT, western union and paypal. 100% payment in advanced for orders less $10,000. 30% deposit and balance before delivery for orders over $10,000.
5 Q: How about your packing ?
A: Carton, Plywood case and foam inside. If you need more, we can pack all goods with pallet
6 Q: What information should be given in the inquiry?
A: Rated power, gearbox ratio, input speed, mounting position. More details, better!
7 Q: How do you deliver our order?
A: We will compare and choose the most suitable ways of delivery by sea, air or express courier.
We hope you will enjoy cooperating with us
