Large 24 FT 13000 Ventilation Aerospace Ventiladores Pmsm Price Manufacturer Blades Gym Warehouse Industrial Ceiling Hvls Fan

Product Description

Product Introduction
The overall design of the fan has been accurately calculated, with high ventilation efficiency, slow and stable wind speed, and produces the best feeling of breeze effect.
Specification
Large DC fan,type GJ-L10-7.2, 7.2m,
Installed weight 160kg,1.5KW,380/220V,3.6A,50 r/min,maximum air volume 13000m³/min.
Advantages
Low cost, low energy consumption, high efficiency: the maximum power required is only 1.5KW, with a single unit covering nearly a thousand square meters of work area.
Comfortable and smooth space: The large ceiling fan with a 6-blade design delivers intermittent airflow that is more similar to natural wind, resulting in higher comfort. The super large ceiling fan hanging on the roof provides a more spacious working area.
High safety and reliability: The large ceiling fan is installed on the roof, which does not interfere with cow production operations; Ultra strength bolt connection, combined with 8mm anti detachment wrapped plastic steel wire rope (tension range 31200N-42900N), corrosion-resistant and safer.
Aluminum magnesium alloy fan blades have the characteristics of high hardness, light weight, and good toughness.
Service life is 15 years, with a 3-year warranty for the entire machine. Replacement of parts outside the warranty period will only be charged at cost.
Domestic permanent magnet motor Type Ceiling Fan

Motor	Dia(m)	Power (KW)	Fan blades NO. (PCS)	Weight (Kg)	rpm	Unit Price (USD)
GJ-L10-7.2	7.2	1.5	6	160	50	1490
Permanent Magnet Motor (6pcs Fan Blade)	7.3	1.8	6	106	55	980
	7.3	1.3	6	88	65	940
	6.1	1	6	82	65	840
	5	0.75	6	72	80	800
	4.2	0.75	6	64	85	770
Permanent Magnet Motor (5pcs Fan Blade)	7.3	1.2	5	82	65	860
	6.1	1	5	80	65	770
	5	0.6	5	72	95	730
	4.2	0.5	5	64	95	640
	3.6	0.5	5	42	100	570
	3	0.5	5	38	110	540
	2.4	0.5	5	34	120	500

Spare Parts
FAQ Q1. Are you a factory or trading company?
A:We are a professional and comprehensive dairy farm equipment supplier integrating R&D, production and sales.Q2.May I visit your factory?
A:Sure, we warmly welcome you all pay a visit to our company. We can arrange pick ups at airport and station. Q3: Can you guarantee your quality?
A: Of course. We have about 20 years experiences in this field. We have skillful production,good workmanship as well as strict QC. we put high quality on our reputation.
Q4: What can you by from our company?
A:Dairy farm design and diary farm equipment: such as rolling curtain, cow fan/ventilation fan, ceiling fan, cow headlock, cow free stall, cow brush,manure scraper, bedding recovery system, manure separator, cow mat,etc.
