Double Loop Wire Binding Machine Without Changing Mold

Product Description

Double Wire Binding Machine DCB-360
The machine is used for binding double wire books, notebooks, calendars, etc. It can bind 1/4"-3/4" without changing the mold. With the integration of unwinding the spool, loops cutting, conveying, and closing, it increased the production efficiency and lowered the cost remarkably.
Technical data:
Work Speed: up to 1000 Volume/hour(Effective speed depends on operator's ability)
Air Pressure: 5-8 Bar
Binding Capacity: 1/4" - 3/4"(No need to change binding mold)
Max. Binding Length: 360mm(14.2")
Power: 1PH 220V 50/60HZ (other voltage on request)
Machine Dimensions (L×W×H):
Main Machine: 1.95×1.27×1.25m
Feeding Reel: 0.8×0.45×1.06m
Conveyor: 2.16×0.37×0.7m
Weight: 300Kg
Oversea workshop
Loading:
Exhibition:
Common questions and answers:
1. Are your a factory or trading company?
We are a professional double wire products machines maker since 2008 and we are the audited supplier in MIC supervised by BV.
2. What about the warranty time?
12 months when you receive the machine. When you get the machine we could send the engineer to supply training service for the first time but the traffic fees and the accommodation arrangement should be on your side. Automatic inline machine training need for 3-4 days and semi-auto machine for 1-2 days.
3. How many molds attached to one machine?
One machine attaches one mold and if you need more sizes, you could make the order.
4.How about spare parts?
Most of the electrical parts and bearings we used are international brands such as SIEMENS AND SCHNEIDER. You could buy them in your local market. For the molds, we have stocks of normal double wire binding size molds. The special mold sizes need 10-15 days.
5. Do you have a dealer in my country?
For the hot selling countries, we have the dealers could supply training service for you and detail your could contact with us.
