Textile Machinery Sheep Wool Flat Carding Machine to Remove The Coarse Hair

Product Description

Product Description
2.1 :Application
1.This machine is not only suitable for sheep wool, cashmere,but also perfect for yak hair, camel hair, alpaca hair and other animal fibers.
2.The flat carding machine adopts a cashmere carding arrangement as follow:double feeder board, double licker-in,cylinder and doffer .which not only can save space for equipment,but also could maximize the effect of removing impurities,coarse wool and dandruff.It is an essential product equipped with negative pressure fully automatic cashmere carding line.
2.2 Main Features:
1.Adopting double feeder board and combined with licker-in to remove coarse wool.In order to increase the rate of coarse wool removing and reduce the number of times of cashmere carding,So as to reduce fiber damage rate as well as raising the output of dehaired cashmere.
2.The licker-in, cylinder and doffer are made up of carding roller and their diameter is 242mm,500mm and 400mm.And then the effect of double permutation and double effect is formed.
3.The falling objects are collected and removed out from the machine by drop collection flat curtain at at the bottom
Remark: Our flat carding machine has been patented,Any questions, please feel free to contact us.
According to different working width, the flat carding machine can be regarded as 1020mm(YQ-FN288 ) AND 1500mm (YQ-FN150)
But based on the diameter of working roller, can be called as YQ-360 and YQ-500,The average output of latter is 2-3kg /hour higher than the former

Product Display
1.One of the necessary unit of carding combined machine
2 .Assembly workshop
3 .Customer's Factory
Main Technical Parameters

Model	YQ-FN288	YQ-FN150
Working Width	1020mm	1500mm
Dimensions(L*W*H)	3345*2040*1100mm	3345*2450*1100mm
Weight	About 2.1 Tons	About 3 Tons
Dragging Power	2.35KW	2.35KW(Variable frequency control feed rate)
Machine Type	Right Hand	Right Hand
Feeding Way	FN288 Feeding Machine	Feeding Machine/Suction Cotton Condenser
Output:	4-8kg/H	5-10kg/H

Company Strength
Certification
Packaging&shipping
Packaging:
Packaging detail:1.wooden case and carton box 2.international standard
Delivery detail:10 days after deposite received
Delivery:
1.Port of Shipment:Qingdao Port
2.Shipment time:Within 7-15 days after payment(It depends on the quantity and model of your order )
FAQ
(1) Q: Are you a manufacturer or agency?
A: We are a professional manufacturer specialized in producing textile machine for more than 20 years, the production ability is up to 800 sets/ mouth. We have our own International Trade Department, so that we can better understand customer's needs and offer a reasonable price.

(2) Q: Is the price offered changeable?
A: Of course, we offer reasonable price and the price is changeable according to purchasing amount. cchanchangeable according to purchasing amount.

(3) Q: How about the quality?
A:The main subassembly are supplied by large companies from Japan, south Korea or German. Key parts are research and design by ourselves.

(4) Q: How about the after-sale service system?
A: Our engineers available to service overseas to provide professional technical support.

(5) Q: Are you available for on-the-spot invitation?
A: Of course we do welcome to visiting our company and have a face-to-face communication to advance mutual business.
