Indoor Outdoor Full Colour Stage Background Glass LED Video Wall Screen Display Rental LED Display P2.9 P3.91 P4.81 P5.95 LED Advertising LED Wall Display Sign

Product Description

Product Description P2 .976 Outdoor SMD full color LED display using the latest generation technology, 112896 points per square meter.
Meet customer requirements.
* High refresh frequency: Using the latest technology ,
Makes use the ordinary general constant current qure drive LED display with high refresh rate, Eliminate screen flicker, Phantom of the opera .
* The box body and the box body: Can slide the slider, To ensure the seamless splicing of the screen .
* The high level of protection cabinet design moisture -proof , Anti -corrosion, Anti mildew, Anti shock, Anti electromagnetic interference etc. Adapt to a variety of environments .
* Optical visual design, Horizontal angle of view and the angle of elevation can reach 140 degrees, The range of any angle, The image is not deformed, Partial color .
Different size cabinets for different requirement:
Outdoor led display screen specification as following:

Model Number	P2 .976	P3.91	P4.81
Model Size (mm)	250*250	250*250	250*250
Pixels Density(dots/m2)	112896	65536	43264
Pixels Pitch (mm)	2.976	3.91	4.81
LED Package lamp	SMD1415LED	SMD1921	SMD1921/2525/2727
Pixel Resolution Dots(W)*(H)	84*84	64*64	52*52
Model Thickness(mm)	16	16	16
Model Weight(KG)	0.55	0.6	0.55
Drive Type	(Constant Drive)	(Constant Drive)	(Constant Drive)
Brightness White Balance(CD/m2)	≥4500	≥4500	≥4500
Cabinet Dimension(mm)	500*500	500*500/500*1000	500*500/500*1000
Power Supply	5V60A* PCS	5V60A* PCS	5V60A* PCS
Screen resolution(dots)	168*168	128*128/128*256	101*104/104*208
Best Viewing Distance(m)	2 .976 - 15	3.9-15	4.81-15
Best Viewing Distance	140 ° (W)140 ° (H)	140 ° (W)140 ° (H)	140 ° (W)140 ° (H)
Temperature	Stoage: -35ºC/+85ºC	Stoage: -35ºC/+85ºC	Stoage: -35ºC/+85ºC
Operation Humidity	10%-75%	10%-75%	10%-75%
Working Voltage	AC220V±10%	AC220V±10%	AC220V±10%
Max Power Consuption(W/m2)	≥400	≥200	≥400
Max Power Consuption(W/m2)	≥800	≥600	≥800
Control Method	Synchronization	Synchronization	Synchronization
Driving Device	Constant Drive	Constant Drive	Constant Drive
Refresh Frequency	≥3840Hz	≥3840Hz	≥3840Hz
Frame Frequency	60Hz	60Hz	60Hz
Luminance Level / Color	RGB256	RGB256	RGB256
Gray Level	65536	65536	65536

Company Profile We are the leading factory of LED display solutions, which has been specialized in R&D, manufacturing and marketing of LED Display Screens. Located in our own industrial park, JLLED covers a district of more than 8000 m², of three floors in one block. We could ensure production capacity of more than 5, 000 square meters per month for the LED displays, thanks to our well equipped automatic production lines, and skilled workers. Our R&D group is made of more than 8% of total employees and most of them are senior technicians, with more than 10 years' experiences in the LED field.
Our led screen export to Italy, USA, Thailand, Romania, Malaysia, Russia, etc for more than 6 years.
Our products have passed the test of international standards certifications, two years warranty ,after two years, only material cost to be charged.
Our services
JL has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
Welcome to make inquiry about our led screen, contact us now!
