Manual Surface Grinding Machine M1022 Surface Grinder
| US$2,000.00-3,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
M1022
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Surface Grinder
Precision
Normal Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Table Size
250X540mm
Wheel Speed
3360rpm
Surface roughness
Ra0.32
Main motor
1.5kw
WHEEL SIZE
200X20X31.75mm
Transport Package
Plywood Case
Specification
950Kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8460190000
Production Capacity
10 PCS/Month
Product Description
MANUAL SURFACE GRINDER FEATURES:
1. The machine has reasonable structure, good rigidity, beautiful appearance, convenient operation.
2. Worktable ball track using steel materials for high precision steel balls, abrasion resistance, easily moved and labor saving, and can be greatly improve work efficiency.
3. Former after skidway through careful scraping flower, not only slide smoothly, and wear-resisting, maintain good accuracy, flexible and convenient operation. manual worktable driven by synchronous belt transmission, wear well.
4. The spindle adopts super precision ball bearing P4, after strict selection after the pre pressure measurement, assembled in the greenhouse, and with the labyrinth design completely waterproof, In order to ensure the service life of the bearing and the grinding surface roughness.
5. No vibration, low noise motor spindle.
6. According to the needs of users with a permanent magnet sucker or electromagnetic sucker.
SPECIFICATIONS:
| MODEL | M1022 | |||
| Working table | Table Size (L× W) | mm | 540×250 | |
| Max movement of working table(L× W) | mm | 560×260 | ||
| T -Slot number×width | mm | 1×14 | ||
| Grinding head | Max distance from spindle center to table surface | mm | 420 | |
| Wheel Size(Outer diameter×width×Inner diameter) | mm | φ200×20×Φ31.75 | ||
| Wheel speed | 50HZ | r/min | 2850 | |
| 60HZ | 3360 | |||
| Feed amount | Vertical feed on handwheel | Per revolution | mm | 4.0 |
| Per graduation | mm | 0.02 | ||
| Cross feed on handwheel | Per revolution | mm | 1.25 | |
| Per graduation | mm | 0.01 | ||
| Motor power | Spindle motor | kw | 1.5 | |
| Coolant pump motor | w | 40 | ||
| Working precision | The parallelism of working surface to base level | mm | 300:0.005 | |
| Surface roughness | μm | Ra0.32 | ||
| Weight | Net | kg | 850 | |
| Gross | kg | 950 | ||
| Overall dimension(L×W×H) | mm | 1680x1220x1720 | ||
| Package dimension(L×W×H) | mm | 1200x1400x1940 | ||
| Contact Us: |
| Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
