Xuzhou 52m Truck Mounted Concrete Pump Hb52
| US$140,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HB52
Type
Concrete Pump
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Cylinder Type
Productivity
120m²/h
Feeding Height
1400mm
Vibrating Amplitude
2.6mm
Certification
ISO9001: 2000
Condition
New
Color
Optional
Empty Weight
15260
Max. Theor. Concrete Output Pressure
7/11MPa
Rated Working Pressure
35MPa
Hopper Capacity
540L
Transport Package
Nude Packing
Specification
14665x2500x990mm
Trademark
NEWINDU
Origin
China
HS Code
87059091
Production Capacity
20units/ Month
Product Description
Xuzhou 52m Truck Mounted Concrete Pump Truck HB52
With SINOTRUCK HOWO Chassis
HB52 concrete pump is the medium size of machine, and widely applied in high buildings and large foundation equipments of bridge, power plant, steel plant, water treatment plant. The machine features environmental care, safety, reliability and advanced.
| Category | Item | Unit | Parameter |
| Chassis | Model | FM440 | |
| Manufacturer | VOLVO | ||
| Max. speed | km/h | 90 | |
| Max. gradeability | 38% | ||
| Min. turning diameter | m | 27.4 | |
| Brake distance | m | ≤10 | |
| Wheelbase | mm | 1995+5205+1370+1450 | |
| Tread (front/rear) | mm | 2028/1872 | |
| Approach angle/departure angle | . | 18/12 | |
| Min. clearance | mm | 270 | |
| Tyre specification | 12.00R20 | ||
| Engine | Model | D13 | |
| Output power | kw/(r/min) | 324/1400~1800 | |
| Max. torque | N.m/(r/min) | 2200/1050~1400 | |
| Displacement | l | 12.8 | |
| Emission Standard | Nation III GB | ||
| Others | Dimension (Length×Width×Height) | mm | 14665×2500×3990 |
| Total vehicle weight | kg | 47000 | |
| Fuel tank capacity | l | 410 | |
| Fuel consumption per 100km | l/100km | 50 | |
| Pumping system | Theoretical output(high pressure/low pressure) | m³/h | 90/138 |
| Concrete pumping pressure(high pressure/low pressure) | Mpa | 13/8.7 | |
| Theoretical pumping times(high pressure/low pressure) | Times/min | 18/27 | |
| Max. diameter of pumping concrete aggregate | 40 | ||
| Feeding height | 1450 | ||
| Placing boom | Pumping slump range | 12-23 | |
| Reach height | 51.5 | ||
| Reach depth | 40 | ||
| Slewing radius | 47.5 | ||
| Slewing angle | 364 | ||
| 1st boom stretch angle | 96 | ||
| 2nd boom stretch angle | 180 | ||
| 3rd boom stretch angle | 180 | ||
| 4th boom stretch angle | 180 | ||
| 5th boom stretch angle | 260 | ||
| Outrigger spanOverall outrigger span | 11020±50 | ||
| Front outrigger transverse span | 10730±50 | ||
| Rear outrigger transverse span | 10430±50 | ||
| Others | Dosing type | S valve | |
| Lubricating method | Automatic lubrication | ||
| Controlling method | Manual/remote control | ||
| Water tank capacity | 650 | ||
| Max. pressure of water pump | 2 |
