Pure Epoxy Resin Powder Coating Super Anti-Corrosion Electrical Insulating
| US$0.30-4.60 | 25 kg (MOQ) |
Basic Info.
Model NO.
UC-SD-1014
Appearance
Powder
Main Raw Material
Epoxy Resin
Method
Spray
Level
Finish Coat
Certification
ISO14001, CCC, RoHS, ISO9001
Substrate
Steel & Aluminum & Metal
Components
Pigment
Formation Mechanism
Conversion Type
Transport Package
PP Bag + Carton Box
Specification
20KG/25KG/Carton
Trademark
FANGTA
Origin
China
Production Capacity
1000 Tons/Month
Product Description
Product Description
| Title | Pure Epoxy Resin Powder Coating Super Anti-Corrosion Electrical Insulating |
| Performance | Great Chemical Resistance Performance |
| Excellent Electric Insulation Property | |
| Excellent Anti Corrosive Property | |
| Excellent Mechanical And Anti-Corrosion Performance | |
| Great Leveling And Gloss | |
| Widely Usage Under Different Temperature Condition | |
| Density | 1.2-1.8 G/Cm3 |
| Film | Film Thickness :40u~150um , Best Recommendation Is 40um~80um |
| Utilization Rate | Average Coverage : 10~12 Square Meter/KG ,With 60um (100% Use Rate) |
| Curing Condition | 140-200°C/15min; Or Customized According To Requirements |
| Method | Corona Electrostatic Spraying ,Electrostatic-Fluidized Bed, Fluidized Beds,Tribo Charging Guns |
| Applicaiton | Mainly Used For Indoor Appliance, Or Coating Of Aluminum/Copper Busbars, New Energy Vehicle Power Battery Shells, Controller Connectors, Motor Rotors, Stators, Transformers, Magnet Wires And Other Metal Substrates That Require High Insulation Performance ; And Single-Layer, Double-Layer And Three-Layer FBE Anticorrosive Coating Of Various Oil And Gas Steel Pipelines |
| Transportation | Two Layers Of Polyvinyl Chloride Plastic Bags In Carton Package, 20 /25kg Per Carton. Non-Dangerous Goods Can Be Transported In Various Ways, But Avoild From Direct Sunlight, Moisture And Heat, And Contact With Chemical Substances. |
| Safety | Non Toxic Substances, And There Is No Toxic Gas Generated During Baking, But Avoid Inhaling Dust During Use, Operators Should Wear Dust Masks, And Minimize The Long-Term Contact Between Skin And Powder Coatings, Which Adhere To The Skin The Paint On The Surface Can Be Cleaned With Soap. |
| Suitable For The Coating Of Metal Products With High Requirements For Corrosion Resistance, Electrical Insulation And Flexibility. Generally, It Is Not Recommended To Be Directly Used For The Surface Coating Of Various Outdoor Products. | |
Company Profile
FAQ
| Q: Is FANGTA a manufacturer or trading company ? |
| A:We are manufacturer since 1986 . |
| Q: Do you provide free sample ? |
| A: Yes ,we provide free sample within 2KGS/Type. |
| Q: Can I require or order customized resins or powder coatings ? |
| A: Yes,We own a strong technical team ,Customize products according to customers' requirements |
| Q: We have met some technical issues during our business ,could you help us to fix it ? |
| A: Yes, for sure ,we provide free technical support to our clinets. |
| Q: How long does it take to deliver our cargos ? |
| A: Leading time is in 2-5 days .If you require customized packages ,It will be about 5-10 days more. |
| Q: How do you guarantee the quality? |
| A: We do 2 round quality tests in 2 labs to ensure the quality,Each round includes processing test and finished product test |
| More questions ,Please feel free to contact us through Email or Whatsapp |
