Durable Cutting Machine for High-Precision Solar Battery Solutions

Product Description

Equipment Use: Discover a revolutionary advancement in cutting technology, meticulously crafted to elevate customer cutting efficiency to new heights. Showcasing an extraordinary roller length of 690mm, coupled with a versatile table size of 170/145mm*690mm*160mm*2, this state-of-the-art machine is engineered with precision to cater to products spanning an ultra-slim 0.3mm to a robust 65mm in thickness. This guarantees unmatched adaptability and precision across a wide array of applications.
CHTXQ-690F Double Plate Multi-Wire Cutting Machine - Key Product Features
1. Independent Drive: Unlock the future of innovation with our machine's four independently driven motors, enabling each roller to operate as the drive shaft. This groundbreaking design minimizes steel line wear on the rollers, substantially extending their lifespan. The expertly designed mounting holes on each roller bracket ensure the spindle's installation aligns with precise coaxial accuracy, achieved through our advanced processing center molding techniques.
2. LED Display Option: Elevate your operational awareness with our advanced LED display, providing crystal-clear and intuitive cutting data. This cutting-edge feature revolutionizes user interaction, making operations seamlessly fluid and well-informed.
3. User-Friendly Design: Experience a transformative under-table design that revolutionizes the loading and unloading process. It allows materials to be effortlessly cut from the bottom up, delivering unmatched ease and efficiency for operators.
4. Versatile Models: Select from our high-speed and standard models, crafted to cater to diverse requirements. The high-speed version enhances performance by increasing line speed, significantly improving cutting efficiency. It accommodates the use of finer diamond lines for cutting uniform materials, enhancing both precision and productivity.
5. Flexibility in Motion: The table features a transverse movement capability, allowing it to glide smoothly back and forth. This ingenious innovation facilitates precise tile cutting and offers the adaptability of single-line cutting functionality, tailored to your specific needs.
6. Enhanced Loading Area: Featuring an expansive loading area of 170/145mm*690mm*160mm*2, our machine significantly amplifies cutting efficiency. It is engineered to handle larger volumes, optimizing your workflow and boosting productivity.
7. Precision and Stability: Our unwavering dedication to precision is embodied in the spindle accuracy of ≤0.01mm, complemented by a patented dust structure (Patent No. ZL201320681902.7). This guarantees stable operation and facilitates easy disassembly for maintenance, ensuring long-term reliability.
8. Effortless Operation: Streamlining your operational demands, the machine is equipped with an automatic lifting shield and a fully expandable workbench. This user-focused design simplifies the loading and unloading of materials and rolls, enabling you to concentrate on productivity with ease.

	unit	parameter
Maximum Worksize	mm	170/145*690*160*2
cutting thickness	mm	0.6~65
running speed	m/min	0~2200
Table lift stroke	mm	220
Table cutting feed speed	mm/hour	0.1~100
The amount of wire output from the supply wheel	Km	30(φ0.2diamond wire)
Diamond diameter	mm	φ0.06~φ0.35axle
Roller outside diameter*number of axles	mm	φ155/φ180*690*4
boundary dimension	mm	≈1830*2800*2650
machine weight	Kg	6500~115000
power		AC380V/50HZ three-phase four-wire
Total machine power rating	Kw	54 above

The double-station multi-wire cutting machine stands at the pinnacle of innovation, employing diamond wire technology for exceptional precision. It processes products with dual plate capabilities simultaneously, featuring a roller length of 690mm and a maximum cutting area of 220mm*690mm*160mm*2. The rotary tool holder function accommodates cutting blade thicknesses from 0.5mm to 65mm, excelling in both single-line and multi-line cutting for hard and brittle material batch processing.
Step into the future with our multi-line cutting machine, capitalizing on cutting-edge diamond line technology. With a roller length of 570mm, it supports a maximum cutting area of 220mm*570mm*160mm. The versatile rotary tool holder function skillfully manages product thicknesses from 0.3mm to 65mm, making it ideal for slicing hard and brittle materials in batch straight sheet processing.
Our compact multi-line cutting machine exemplifies efficiency, integrating diamond line technology and available in both single and double station models. Designed for small batch straight sheet processing, it allows for effortless specification transitions, handling sheet thicknesses from 0.5mm to 30mm. It supports both single-line and multi-line cutting, perfect for small batch processing of hard and brittle materials.
Yutian Changtong Eiectron Co., Ltd. proudly traces its illustrious journey back to 1998, originally established as Yutian Changtong Electronics Factory. In a landmark transformation in 2007, it evolved into Yutian Changtong Electronics Co., LTD. Showcasing its unwavering dedication to innovation, it was distinguished as a high-tech enterprise in Hebei Province as early as 2001 and further elevated to the prestigious status of a national high-tech enterprise in 2016. The company orchestrated a strategic expansion by inaugurating a branch in Yantai, Shandong Province in 2006. Today, it stands as a national high-tech powerhouse, flawlessly integrating research and development, production, sales, and unparalleled service excellence.
Product Introduction
Main Products: Immerse yourself in our diverse array of cutting-edge offerings, including superior quartz crystal chips (frequency sheets), premium-grade green silicon carbide powders, state-of-the-art multi-line cutting machines, and pioneering electronic mechanical equipment that redefine innovation.
Quality Certification
Since its inception, Yutian Changtong Eiectron Co., Ltd. has thrived on the transformative principle that technology is the paramount driving force for productivity. By fostering strategic collaborations with esteemed academic and research institutions including Northeastern University, Yantai University, Hebei University, Dongguan University of Technology, Beijing Institute of Printing Machinery, and the prestigious Chinese Academy of Sciences (units 203, 45, 707, 607), the company has achieved groundbreaking advancements. These esteemed partnerships have resulted in the acquisition of numerous patents, with one particularly distinguished patent proudly featured in the esteemed National Science and Technology Database.
Yutian Changtong Eiectron Co., Ltd. stands as a shining beacon of excellence, proudly celebrated as a 'High-Tech Enterprise of Hebei Province'. The company has been honored with numerous prestigious accolades including 'Small and Medium-Sized Enterprises of Science and Technology in Hebei Province', the esteemed title of 'National High-Tech Enterprise', and the acclaimed distinction of a 'Specialized and Special New Enterprise'. Further solidifying its prestigious reputation, it is recognized as a 'Municipal Enterprise Technology Center', 'Municipal Industrial Design Center', and a distinguished 'National 3A Credit Enterprise'. These illustrious accolades underscore our relentless pursuit of innovation and our unwavering commitment to unparalleled industry excellence.
Value Concept
Guided by unwavering principles of 'Ethical, Integrity Management', Yutian Changtong Eiectron Co., Ltd. has consistently earned admiration as an exemplary A-level tax entity across provinces, cities, and counties. Our steadfast dedication to honesty and quality has bestowed upon us the honorable designations of 'Honest Enterprise', 'Quality and Credit Enterprise', and 'Outstanding Builders of Socialist Undertakings with Chinese Characteristics'. These esteemed accolades are a testament to our steadfast commitment to integrity and unmatched quality in every aspect of our business endeavors.
