Module spare parts D674A906U01 FET3251COP1B4COH2

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

D674A906U01 FET3251COP1B4COH2

Safe torque off output (XSTO OUT) Connector pitch 5 mm, wire size 2.5 mm2 To STO connector of inverter module Control panel connection (X13) Connector: RJ-45 Cable length <3 m (10 ft) Ethernet connection (XETH) Connector: RJ-45 This connection is not supported by the firmware. SDHC memory card slot (SD CARD) Memory card type: SDHC Maximum memory size: 8 GB The terminals on the board fulfill the Protective Extra Low Voltage (PELV) requirements. The PELV requirements of a relay output are not fulfilled if a voltage higher than 48 V is connected to the relay output. 28 Technical data Ground isolation diagram XPOW +24VI 1 GND 2 +24VI 3 GND 4 XAI +VREF 1 -VREF 2 AGND 3 AI1+ 4 AI1- 5 AI2+ 6 AI2- 7 XAO AO1 1 AGND 2 AO2 3 AGND 4 XD2D B 1 A 2 BGND 3 SHIELD 4 XRO1, XRO2, XRO3 NC 11 COM 12 NO 13 NC 21 COM 22 NO 23 NC 31 COM 32 NO 33 XD24 +24VD 5 DICOM 6 +24VD 7 DIOGND 8 XDIO DIO1 1 DIO2 2 DIOGND 3 DIOGND 4 XDI DI1 1 DI2 2 DI3 3 DI4 4 DI5 5 DI6 6 DIIL 7 XSTO OUT 1 SGND 2 IN1 3 IN2 4 XSTO OUT IN1 5 SGND 6 IN2 7 SGND 8 * Ground Common mode voltage between each AI input and AGND is +30 V *Ground selector (DICOM=DIOGND) settings DICOM=DIOGND: ON All digital inputs share a common ground (DICOM connected to DIOGND). This is the default setting. DICOM=DIOGND: OFF Ground of digital inputs DI1…DI5 and DIIL (DICOM) is isolated from DIO signal ground (DIOGND). Isolation voltage 50 V. Technical data 29 Other information Cybersecurity disclaimer This product is designed to be connected to and to communicate information and data via a network interface. It is Customer's sole responsibility to provide and continuously ensure a secure connection between the product and Customer network or any other network (as the case may be). Customer shall establish and maintain any appropriate measures (such as but not limited to the installation of firewalls, application of authentication measures, encryption of data, installation of anti-virus programs, etc) to protect the product, the network, its system and the interface against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. ABB and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information. Battery Real-time clock battery BR2032 Protection classes Degree of protection (IEC/EN 60529) IP10 Enclosure type (UL 508C) UL Open Type Overvoltage category (IEC 60664-1) II Protective class (IEC/EN 61800-5-1) I Protective class (IEC 62109-1) II Ambient conditions Air temperature in operation 0…70 °C (32…158 °F) Materials Housing Hot-dip zinc coated steel, cover painted Label Polycarbonate Package Cardboard Applicable standards EN 61800-5-1:2007 Adjustable speed electrical power drive systems. Part 5-1: Safety requirements – electrical, thermal and energy EN 61800-3:2004 Adjustable speed electrical power drive systems. Part 3: EMC requirements and specific test methods IEC/EN 62109-1:2010 Safety of power converters for use in photovoltaic power systems Part 1: General requirements UL508C:2002 UL Stand
