10kw 110V and 220V 1p 10kVA 10000va Automatic Stabilizer Voltage Regulator AVR

Product Description

10KW 110V and 220V 1P 10KVA 10000VA Automatic Stabilizer Voltage Regulator AVR Product Description The rated capacity of TND(SVC) series single phase automatic voltage regulator (hereinafter referred to as TND voltage regulator) ranges from 500VA to 80KVA for normal products. The normal voltage regulation range is 170V to 260V. TND voltage regulator is mainly composed of copper coil, servo motor, auto-control circuit, and carbon brush etc. When voltage fluctuates or load varies, the control circuit would give out signal to servo motor to move the carbon brush along the surface of the copper coil, so as to maintain the voltage stabilized all the time.
Product Parameters

Product Name	Single Phase AC Power Automatic Voltage Stabilizer/Regulator
Rated Capacity	10KVA (Could be customized)
Product Model	TND(SVC)-10KVA
Input Voltage Range	220VAC±20% (Could be customized)
Rated Output Voltage	220V/230V/240V/110V/(Could be tailored)
Working Frequency	50HZ-60HZ
Output Accuracy	±2%
Insulation Class	F
Waveform Distortion	No Additional Waveform Distortion
Phase	Single Phase
Working Temperature	-10ºC~+50ºC
Ambient Relative Humidity	30%-80%
Protection Class	IP 23 (Could be tailored)
Cooling Way	Dry Type Air Colling
Insulation Resistance	≥5MΩ
Working Effiency	>90%
Current Type	AC
Product Type	Servo Motor Type
Regulation Method	Automatic Regulation

Product Advantages TND voltage regulator features in fast response speed, high efficiency, high output accuracy, automatic voltage regulation, no additional waveform distortion, sound voltage regulation performance, and suitability for constant work etc. It is designed with various protection functions, including over-voltage, under-voltage, over-current protections.
Product Details
The displaying system includes the voltage meters for indicating input voltage and output voltage, and pilot lamps for indicating the working status of the automatic voltage regulator stabilizer. It's user-friendly for customers to monitor the data at real time.
These four parts are the major elements for this 10KVA single phase automatic voltage regulators stabilizers. High quality parts helps to facilitate the stable performance of the AVR.
For sound heat emmision, the cabinet/enclosure of the automatic voltage stabilizer is designed with multiple heat emission window blinds.
This part shows the wiring terminals of the AVR and the inner structure of the 20KVA single phase automatic voltage regulator. It is easy for users to connect wires.
This part shows the handles of this automatic voltage regulator stabilizer. The design is user-friendly.
Product Cases
Ewen Electrical has been dedicated to designing customized products for our customers. If you have specific technical requirements, the AVR could be customized according to your needs.
Product Applications TND voltage regulator is widely applied in places which needs stable single phase voltage. It is an ideal home voltage supply or non-industrial voltage stabilization product.
Company Profile
Ewen Electrical adheres to the business policy of seeking development by science and technology and survival by quality, and wins the recognition of customers with excellent technology, advanced equipment, high-quality products, thoughtful service, flexible business methods and good corporate reputation.
Certifications Ewen attaches much importance to product quality by upholding the principle of developing by technology and surviving by quality. We produce goods according to ISO quality system standards and international and domestic industrial standards, which wins trusts of customers home and abroad. In the future, we would be dedicated to creating economic benefits and social benefits by increasing technology development budget, so as to enable us to become a energy-saving, environmental, technology-oriented enterprise.
Q: How long is the lead time?
A: It's normally five to ten days. Certainly it depends on the quantity and product requirements. If the quantity is not that large, 10 days or so. If it's normal products, it takes us less than 10 days to produce it. For large quantity and customized products, it needs 20 to 30 days.
Q: How do you control the product quality?
A: From material coming to product manufacturing, we have professional staff who are responsible for quality inspection. Only the product is up to standard, can we ship it to our customers.
Q: What is the payment terms?
A:FOB/CIF/CFR,normally with 30% deposit for normal products and at least 50% advance payment for tailored products and all balance paid before shipment.
Q: How long is the warranty?
A: We provide one year warranty for our customers. If there is any problem occurred to the product, we could supply the spare parts for you for free. During the warranty period, we would provide technical support with you in case there is any question.
Q: Could you please provide technical support in product installation?
A: Yes, certainly. We have a professional technical team which is responsible for product installation and application guidance for our customers.
Q: What certificates have you obtained?
A: We have obtained CE and ISO:9001 certificates so far. We are trying to get more certificates related to our products.
Q: Tell me the package of your products?
A: For large products, we use strong wooden case for protection. For small products, we use carton.
Q: Can you put our logo on your product?
A: Yes, we accept OEM and ODM. If the quantity is large, your logo could be put on our products.
Q: Where is your major market?
A: Our markets include central Asia, East Asia, South Asia, Africa, South America, and North America etc.
Q: What about your capacity?
A: It depends on the product. For instance, for small-power products, we could produce ten thousand pcs a month while 2000 pcs for larger-power products.
Q: What is the material of your products?
A: The major material is copper and aluminum. It is decided upon your requirements and your budget.
