4KV lightning protection 48 Port Gigabit POE Switch Unmanaged with 2 1000Mbps SFP Uplink

Product Description

Detailed Photos
About this item 48 Port Gigabit POE+ Switch Includes 48x10/100/1000Mbps POE+ RJ45 Ports, 2 Gigabit Uplink SFP Port. SFP ports could be connected to different devices such as routers, NVRs, etc. Widely used in IP cameras, Wireless Access Point, IP Phone, Computer Networks, etc. 800W High Power Budget Build-in 800W high POE output power, each POE port can automatically detect and recognize IEEE 802.3af/at and 15.4w/30w POE Devices. Switching capacity up to 56Gbps, with better data performance. 8K Mac address table, more devices can be connected and suitable for large networks. IP30 Protection Level4KV lightning protection design protects the product and equipment from damage even in bad weather. With industrial grade fan and metal housing, it can work in a wide temperature range of -10°C to +55°C. Easy to Use Automatically detect devices, support Plug and Play, just plug in the power cord and network cable, there is no configuration is needed. Managed POE Ethernet switch makes your work easier and more stable. Support desktop and 19 inch rack mount installation. Suitable for home, office, small and medium business. Customer Service&Technicoal Supportive switches are rigorously tested for reliability, quality, and performance. We supply a year warranty for whole products and lifetime technical support.

Buffer Memory	4M
Network Protocol	IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000base-X; IEEE802.3u 100Base-FX; IEEE802.3x.
Power Supply	Built in switching power supply, AC100~240V 50-60Hz
Dimension (inch)	17.3 x 11 x 1.7 in
Weight (lbs)	9 lb
Protection	IEC61000-4-2(ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-5(Lightning protection/Surge): Power:CM±4kV/DM±2kV; Port: ±4kV
Installation Method	Desktop type, 19-inch 1U cabinet installation
Operation TEMP / Humidity	-10~+55°C:5%~90% RH non condensing
PoE Port	48*10/100/1000Mbps PoE Port
PoE Standard	IEEE802.3af/at;15.4W/30W
Total PWR / Input Voltage	800W (100-240V)
Ethernet Port Feature	10/100/1000Base-T(X) automatic detection, full/half Duplex MDI/MDI-X adaptive
Switching Capacity	56Gbps (non-blocking)

ELECTRICALCHARACTERISTICS
