Small Hydraulic Residential Elevator Home Lift Villa Lift Elevators

Product Description

Small Hydraulic Residential Elevator Home Lift Villa Lift ElevatorsProduct Description
Passenger Elevator( MR)
The launch of Asia FUJI small computer room elevator has led the elevator industry to move toward small machine room equipment configuration.Small machine room elevator can meet both passenger and freight transportation; they are suitable for office, hotel,residential building and skyscraper.Asia FUJI small machine room elevator is driven by permanent magnet gearless traction machine to ensure safe and reliable operation,lower noise and better performance.
Small machine room, space-saving, lower the cost, high efficiency
The use of small machine room elevator technology not only speeds up the construction progress and ensures the smooth operation of the construction project, but also easy to replace the traction machine when it needs to be modified, while the traditional drive system cannot meet such a convenient transformation.
Small machine room passenger elevator parameters

Capacity (Kg)	Person	Speed (m/s)	Entrance (mm)	Clear car dimension (mm)	Caroutstide dimension (mm)	Clear hoistway dimension (mm)	Machine room dimension (mm)	Pit depth mm	Overhead height mm	Pit reaction load (KN)		Machine room reaction load (KN)		Rated power (KN)	Power supply capacity		Lead-in wire
Q	NO.	V	OP	CWXCD	SWXSD	HWXHD	MWXMDXMH	PD	OH	R1	R2	R3	R4	KW	KVA		MM2
450	6	1.0	700	1200x1100	1252x1266	1800x1800	1800x1800x2200	1500	4400	50	40	20	8	3	3.6		4
		1.5						1600	4500					4.8	5.8		4
630	8	1.0	800	1400x1100	1452x1266	2000x1800	2000x1800x2200	1500	4400	68	54	24	10	4.3	5.2		4
		1.5						1600	4500					6.8	8.2		6
800	10	1.0	800	1400x1350	1452x1516	2000x2050	2000x2050x2200	1500	4400	76	60	28	12	5.4	6.5		6
		1.5						1600	4500					8.6	10.3		6
		1.75						1700	4600					9.6	11.5		6
		2.0						1800	4700					11	13.2		6
1000	13	1.0	900	1600x1450	1652x1616	2200x2200	2200x2200x2200	1500	4400	90	72	32	15	6.4	7.7		6
		1.5						1600	4500					10.7	12.8		6
		1.75						1700	4600					11.7	14		6
		2.0						1800	4700					13.4	16.1		10
		2.5						2000	4900					17	20.4		10
		4.0						3800	5900					27.7	31.5		10
1250	16	1.0	1000	1800x1550	1852x1716	2400x2300	2400x2300x2200	1500	4400	105	80	36	18	8.5	10.2		6
		1.5						1600	4500					13.5		6.2	10
		1.75						1700	4600					14.8		7.8	10
		2.0						1800	4700					17	20.4		10
		2.5						2000	4900					22	26.4		10
		4.0						3800	5900					34.6	39.6		10
1350	18	1.0	1100	1900x1600	1952x1766	2500x2300	2500x2300x2200	1500	4400	115	90	40	20	9.3	11.2		6
		1.5						1600	4500					14.9	17.9		10
		1.75						1700	4600					16.3	19.6		10
		2.0						1800	4700					18.7	22.4		10
		2.5						2000	4900					23.4	28.1		10
		4.0						3800	5900					36.8	44.2		10
1600	21	1.0	1200	2000x1700	2052x1866	2600x2400	2600x2400x2200	1500	4400	136	105	48	26	11	13.2		6
		1.5						1600	4500					17.5	21		10
		1.75						1700	4600					19	22.8		10
		2.0						1800	4700					22	26.4		10
		2.5						2000	4900					27.5	33		10
		4.0						3800	5900					34.2	41		10

Detailed Photos
Asia FUJI Elevator
Adopting VVVF control technology and permanent magnet synchronous motor technology, saving energy and protecting the environment, without occupying space, it is a competitive home elevator product that possess different style, multi-functional and so on.
Asia FUJI Elevator become the best choice for the renovation of old buildings due to small in size, high in efficiency, light in weight, easy to control of the permanent magnet synchronous traction machine.Adopt NICE3000 new integrated control system. Using high-performance vector control technology and digital direct parking technology, the operation curve that is most suitable for human function is calculated according to the actual floor spacing
The arrangement of Control cabinet meet the requirements of the normal operation of the power system, facilitate inspection and repair, and do not endanger people and surrounding equipment security. Safety components
Safety components, at least 20 experiments, own brand, high reliability
Under the control of the system, the failure rate of the elevator is greatly reduced, which not only operates reliably, but also saves energy , and with a complete brake control component (speed limiter, safety gear, guide shoes, bumper, tensioner) to ensure the long-term normal operation and safety protection function of the safety control system are provided.Decoration Options
Company Profile
Asia Fuji Elevator (Linyi) Co., Ltd is a joint-stock enterprise integrating R & D, design, production, sales, installation and maintenance of all kinds of elevators. Located in Pingyi County, Linyi City, Shandong Province, it is a key construction project attracting investment in Linyi City in 2015, with a total area of 300 Mu and a total investment of 1.3 billion yuan. Products include passenger elevator, sightseeing elevator, household elevator, business elevator, medical elevator, villa elevator, cargo elevator, car elevator, escalator and sidewalk. At present, the company has won the honors of "national quality inspection stable and qualified products", "national quality integrity excellent enterprise" and "high tech enterprise", and has won 11 technical patents in the elevator industry.
The intelligent production line adopts ABB6700 series products, and adopts 360 rotation type, from feeding to bending, to enter the roll line turnover work, and at the same time, enters the stiffener, head, gluing and arc welding process. This production process is composed of a single direction private service control motor platform and a double head spot welding machine; it has high stability and efficiency, can achieve the best manufacturing accuracy.
Start with a board, make a door panel cut step by step, and then put it in the ABB Engineering. After completing the following operation process, the ABB robot and the line on the other side (shearing machine cutting plate → punching machine punching → bending → welding) works the same way.
Certifications
At present, the company has obtained honors like the "National Quality Inspection Stable and Qualified Products", "National Quality and Honest Outstanding Enterprise" honor certificate and "High-tech Enterprise" and has won 15 patents in the elevator industry.In 2019, the company's leadership pioneered the company's development direction as a ""one-stop product service provider of high-end intelligent transportation equipment", marking that Asia Fuji Elevator officially entered the field of intelligent three-dimensional garages and intelligent warehousing to solve the "parking difficulties"
Packaging & Shipping
Project Case
FAQ
Q1.Why choose us?
A: Asia Fuji Elevator is a joint-stock enterprise integrating elevator R & D, design, production, sales, installation, and maintenance. Famous brand, already been confirmed by many customers Domestic and overseas Sample projects are customers voice for our quality.
Q2: What advantages do you have?
A: The intelligent production line adopts ABB6700 series products, and adopts 360 rotation type, from feeding to bending, to enter the roll line turnover work, and at the same time, enters the stiffener, head, gluing, and arc welding process. These technologies could guarantee the machine's accuracy.
Q3. What information is absolutely needed before asking for the price?
A: 1. How many people? ( 6 persons for 450kg,8 persons for 630kg, 10 persons for 800kg, etc.)
2. How many floors/ stops/ doors?
3. What's the shaft size? (width by depth)
4. Is there a machine room on the top of the shaft?
5. What about speed needs?
Q4. How can we guarantee the good quality of your products?
A: In during the production process we will inspect all purchased and produced parts and take a record after put in crates, before shipping out we will do the final inspection and mockup the cabin and sling set, this part take photos and videos as a record to make customer being at ease.
Q5. What certificates do you have?
ISO9001 / CE / SGS / EN81 / EN115 / SASO
Q6. What about the delivery time?
Normally 25~35 working days
Q7: What's the payment term?
A:30% in advance, 70% after customers inspection, before loading
Q8. What about the packaging?
A:All elevator parts will be packed into solid wooden cases. Some parts will be wrapped by the film so that guarantee the machinery part not be destroyed after long time transportation.
Q9 . What's your guarantee time?
A:We can provide 18 months guarantee period, during this time, we will send free replacements to you. our service has no time limit.
Q10. About ower requirement?
In China, usually, the power is 380V, you could share with us if you have the special requirement on the power requirement, if your need a different power, we could equip transformer for you.
