Professional Gasoline Carbon Steel Land Loading Arm (for Fuel Loading unloading)
| US$1,200.00-2,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
AL2503
Certification
ISO9001
Tank Marerial
Metal Tank
Type
Middle Pressure Storage & Transportation Equipment
Storage Objects
Solid, Liquid, Gas
Color
Light Grey or Customized
Seals
PTFE
Quality Guarantee
1 Year
Application
Truck Tanker, Rail Car, Marine
Accessory One
Quick Coupling
Accessory Two
Break Away Coupling, Liquid Level Alarm
Transport Package
Wooden Case or Plywood Case
Specification
DN50, DN80, DN100, DN150
Trademark
LOADARM
Origin
China
HS Code
8428909090
Production Capacity
5000 Sets / Year
Product Description
The structure of AL2503 land loading arm:
Our loading arm in the workshop:
The general introductio for land loading arm:
Our land loading arm is especially designed for transporting fluid between piping system and tanker, which shall be designed for different tanker, liquids and site conditions.
Equipped with loading platform, folding stairs and safety cage to make the land loading arm into a complete loading system.
By level location or quantitative monitoring, while fluid level exceed the present value, provide the sound and visual alarm or the remote signal.
According to the products, models and requirements of customers, the operating modes could be manual, pneumatic or hydraulic etc.
The basic technical data for AL2503 land loading arm:
| AL2503 is a typical of bottom loading arms.The type of loading arm usually connects to the tanker by flanges or quick coupling. It has good sealing performance. | |
| Places Applied | Bottom closed loading or unloading |
| Applications | Product oil, chemicals, etc. |
| Nominal Diameter | DN50~DN100 |
| Working Temperature | -196~250ºC |
| Working Pressure | PN1.0~PN4.0 |
| Material of pipeline | Carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc. |
