Made in China Front End Loader for Dongfeng Tractor Lovol Tractor Yto Zoomlion Tractor for Sale

Product Description

Made in China front end loader for Dongfeng tractor lovol tractor yto Zoomlion tractor for sale
Ms. Andy Quick reply~
Product Description
24-Year manufacturer Sunco TZ Series Front End Loader is Top Quality made in China!!
Mounted: LOVOL FOTON YTO DONGFENG ZOOMLION tractors and many other tractors
Loader attachment: Bucket, grab, lift, trimmer,plow, blower, sweeper etc.
Powered: 25hp-220hp

Detailed Photos
Product Parameters

Loader Model			TZ02D	TZ03D	TZ04D	TZ06D	TZ08D	TZ10D	TZ12D	TZ16D
Matching Tractor		hp	15~25	20~40	30~55	45~60	55~75	70~100	90~140	140~180
Max. Lifting Height at Implement Pivot Pin	H	mm	2350	2550	2740	3010	3400	3710	3970	4260
Dumping Height	A	mm	1730	1840	2100	2370	2480	2720	3000	3200
Overloading Height	L	mm	2170	2370	2560	2830	3220	3490	3770	4000
Dumping Distance	W	mm	370	500	600	640	690	740	900	900
Ground Clearance at Arm Pivot Pin	B	mm	1120	1200	1360	1500	1630	1780	1930	1930
Max. Tip in Angle	X	°	48	48	48	48	54	54	54	54
Tip out Angle	Z	°	52	58	58	58	58	58	58	58
Crowd Angle at Lowered Lift Arm	V		140	135	135	135	135	145	145	145
Digging Depth	S		90	100	100	120	140	180	200	200
Lifting Force at Implement Pivot Pin	Q1		1821	2224	2144	2150	1997	2308	2403	2620
	Q2		1184	1474	1321	1286	1187	1452	1690	1850
Bucket Model(Standard)			02DP15	04DP125	04DP140	06DP150	08DP160	08DP170	12DP200	16DP240
Bucket Width			1250	1250	1400	1500	1600	1700	2000	2400
Bucket Capacity			0.16	0.18	0.21	0.35	0.4	0.44	0.7	1.6
Rated Lifting Capacity			200	300	400	600	800	1000	1200	1600

Packaging & Shipping
Our Advantages
Advantage of SUNCO:
1. Strong Technology team for design, OEM.
We are partner China YTO/ LOVOL /Dongfeng/Zoomlion tractors for more than 20 years.
2. Large capacity of production with complete procedures,
with annual export more than 12000 sets, and 30000 units attachments for 15 years.
3. High quality and sound services.
Warranty period: 1 year.
We will send the parts for free in the warrenty period if it is quality problem.
And, we can supply parts out of the warrenty period, free online services.
4. Main Products:
Front end loader, backhoe attachment, forest machinery, Snow remove machinery, front linkage, compost turner, new products etc.
Other Machines of SUNCO
Hedge trimmer Trimmer head Arm mower

3 point timmer compost turner Backhoe

FAQ
Q1: Are you factory?
A: Yes, Exactly!!
we are leading manufacturer with 24 years experiences!!
