Coffee Tea Packaging Food Grade Material Design Automatic Paper Can Making Machine
| US$5,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
CFJG-SK-50
Paper Core Usage
Industry
Gumming Type
Double Side
Layers of Roll Paper
3-10
Reelpipe Speed
1-25m/Min
Wall Thickness of Paper Tube
0.5-5mm
Certification
CE
Condition
New
After-sales Service
12 Months
Transport Package
Wooden Pallet
Specification
4200*1600*1800mm
Trademark
Chuangfeng
Origin
China
HS Code
8441809000
Product Description
2. CFJG-SK-50 Servo Controlled Paper Tube Making Machine| Technical Parameter | |||
| Paper Layer | 10 Layers | ||
| Inner Diameter | 20-100mm | ||
| Wall Thickness | 0.5-5mm | ||
| Winding Speed | 1-25meters/min | ||
| Winding Nose | Double noses single belt | ||
| Length Fixing | By Encoder | ||
| Cutting Way | Servo Synchronous Tracking Cut | ||
| Cutting Length | 500-5000mm (speed will be low when cutting length < 1000mm) | ||
| Gluing Way | Double sides | Configuration | |
| Shaft Fixing | by Flange | Gluing System | 10 Layers |
| Speed Control | By Inverter | Paper Reel Stand including Paper Lifting Device | 10 Layers Integral Type |
| Operator | 1-2 persons | ||
| Working Air Pressure | 0.6Mpa | Inner Paper Shelf | 1 Set |
| Power Supply | 380V/3Phase/50Hz | Discharging Shelf | 1 Set |
| Measurement & Weight | Mandrel Shaft (mold) | 2 Pieces | |
| Measurement | 4200*1600*1800mm | Belt | 4 Pieces |
| Working Space | 11000*8000mm | Useful Tool | 1 Set |
| Weight | 3700kgs | Extra blades | 5 Pieces |
2023 Latest Model
Double-heads Single Belt Spiral Winding
Single Knife Online Cutting System; Servo Motor Controlled;
Cutting Length 500-5000mm ((speed will be low when cutting length < 1000mm))
Equipped with 10 layers integral type paper reel stand have hoist paper lifting device
Equipped with 10 layers double sides spraying type gluing unit
Inner paper stand 1 set
Paper Tube Collector * 1 set
Finished tubes
