High Performance 95% Total Reflectance PVD Coating Aluminum Sheet
Basic Info.
Model NO.
L95
Grade
1000 Series
Temper
O-H112
Window & Door Aluminium Profile
N/a
Alloy
Alloy
Surface Finishing
PVD Coated
Alloying Ingredient
1085
Certification
ISO, RoHS, TUV, ISO9001
Polished Aluminum Profile
N/a
Total Reflectance
95%
Diffuse Reflectance
5%
Sample
Avaliable
Tolerance
10%
Process
PVD Coating(Physical Vapor Deposition)
Processing Service
Cutting
Surface
Coating
Name
High Reflective Aluminum Sheet
Thickness
0.7mm
Alloy or Not
Non-Alloy
Delivery Time
22-30 Days
Surface Treatment
Coated
Application
Lighting
Width
1250
Transport Package
Exporting Wooden Case
Specification
0.3mm-1mm
Trademark
SMMT
Origin
Fujian, China
Product Description
SMMT's high performance Al mirror product "L95" is specially designed to perform stable in CoB-LED high temperature and environmental conditions. For achieving higher specular reflectance, the L95 product is applied onto Anodized Al metal strips which provide a low scattering, smooth and hard surface prior to our coating. All layers are PVD coated and applied by the new continuous air-to-air vacuum coating machine from Germany. Our technology gives the possibility to coat our metal strips with high efficiency, high speed and high stability of product properties and quality among the whole length of the metal strip coil. Product & Applications Product Parameters| Product Name | High Performance Mirror | "L95" |
| Substrate Specification | Material | Aluminum Strip |
| Width[mm] | <=1250 | |
| Standard Thickness[mm] | 0.3-1.0 | |
| Standard Alloy | 1085 | |
| Temper | H18-H19 | |
| Surface | anodized | |
| Mechanical Property | Tensile strength [N/mm2] | >=140 |
| Yield strength [N/mm2] | >=120 | |
| Elongation A 50% | >=2 | |
| Bending radius for forming | >=1.5 x strip thickness | |
| Optical Property | Total reflectance (Y/D65/2º)[%] | 95±2 |
| Diffuse reflectance (Y/D65/2º)[%] | <5±2 | |
| Iridescence | no visible iridescence | |
| Payment Term | TT, LC | |
| Packing | 1. Product surface attached with proctective film 2. plastic film sealed 3. Anti-collision foam 4. Drying agent 5. seaworthy exporting wooden case | |
| Delivery Time | Future goods: 25-35 work days; Ready Stock: 7- 10 days | |
