Hot and Cold Thermal Cycling Testing Machine for Plastic Pipe

Product Description

Plastic Pipe Thermal Cycle Testing Machine

Product Description Plastic Pipe Thermal Cycle Testing Machine is applicable to all kinds of plastic pipes, pipe fittings and pipe systems. Under the condition of pressure and different temperatures within the specified time After completing the test to check the leakage and rupture of pipes and pipe fittings.
Test Standard
ISO1167, ASTM D1598, ASTM D1599, ISO10508 and the equivalent.
Product Specifications

Model	HD-R902
Pressure range	4.00bar-16.00bar, 0.400Mpa-1.600Mpa (Customizable)
Pressure control accuracy	±0.05 Mpa
Number of test stations	6
Alternation time between hot and cold water	< 60s
Cycle period	300s-1200s
Maximum measured cross-sectional area	4200mm² or 6200mm²
Maximum straight pipe length of sample	3700mm
Control mode	PLC control
Display mode	touch screen display
Number of cycles	selectable 1-100000
Temperature range (cold water)	20ºC to RT (selectable) accuracy:±2ºC
Temperature range (hot water)	RT to 95ºC (selectable) accuracy:±1ºC
Temperature display error	1ºC
Temperature uniformity	≤±1ºC
Inlet and outlet temperature difference	2ºC
Power supply	380V±10% 50Hz
Overall dimensions	4500(L)×3000(W)×2000(H)mm(6 stations)
Installation dimension	6000(L)×4000(W)×3000(H)
Optional function	A: Flow measurement and regulation (optional)
	B: Prestress application system (optional)
Model: HD-R902-200A	With Flow measurement and regulation
Model: HD-R902-200B	With Prestress application system
Model: HD-R902-200AB	With Flow measurement and regulation and Prestress application system
