Product Description

1. FEATURES
(1) This machine may be used for surface cutting, drilling, milling, and tapping.
(2) This machine is of fine quality, can be operated easily, it is not limited to skilled operator.
(3) The drilling and milling operation can be performed by two methods:
1) Hand operation, which makes quick feeding drilling.
2) Worm gear feed operation, which makes slow feeding milling.
(4) Many of the adjustable nuts are bronze, for adjusting thread clearance and reducing wear. these bronze parts also allow screws to rotate smoothly and improve accuracy.
(5) The vertical column is very strong and stiff, which makes the machine very stable and improves accuracy of manufactured parts.
(6) The machine headstock is cast iron, it has been heat-treated, stress-relieved, and precision machined.
(7) Machine gears are precision ground for smooth operation.
(8) Speeds can be easily changed.
(9) Tapping can be done in either rotation, working depth can be controlled by using a positive stop gauge.
(10) The head can be turned in two rotation for a satisfying desired angle.


1.square column 2.lock screw 3.micro feed handwheel
4.lock handle 5.feed handle 6.crank 7.handwheel
8.cross lock screw 9. longitudinal lock screw 10.lock handle 11.shift handle 12.change speed handle 13.switch

SPECIFICATION
Model	ZX-45
Max.drilling capacity	45mm
Max.face mill capacity	80mm
Max.end mill capacity	28mm
Max.tapping capacity	M12
Max.spindle stroke	130mm
Max.distance from spindle axis to	260mm
column
Swivel angle of headstock at perpendicular direction	±90°
Max.distance between spindle nose to table	450mm
Spindle taper	M.T.4 OR R8
Working area of table	800mm×240mm
Forward and backward travel of table	175mm
Left and right travel of table	400mm or 500mm
Spindle speeds (4P)	50HZ: 80,145,260,375,710,1250 RPM
	60HZ: 95,175,310,450,850,1500 RPM
Motor	1.5KW (1HP)
Length	820mm
Width	160mm
Overall height (without stand)	1020mm
Net weight/gross weight	325kg/375kg

Standrad accessories:Allen wrench, Wedge-Wrenches, Drill chuck arbor, screw, draw bar and washers
Optional accessories:
1.Machine stand
2.Power feed
3.90mm paraller vise
4.120mm paraller vise
5.Drill chuck
6.milling cuttter holder
7.Changing sleeve
8.Mill chuck
9.Auto-tapping electrical
10.Boring bar
11.Working lamp
12.Coolant system
13.DRO/XY
3.Machine photos
4.Manufacturing Capability
