BestScope BS-2020M Economic LED Education Student Outdoor Easy Use Biological Microscope
| US$255.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BS-2020M
Type
Biological
Number of Cylinder
Monocular
Mobility
Desktop
Kind of Light Source
Ordinary Light
Shape
Cylindrical Shaped Lens
Usage
Teaching, Research
Principle
Optics
Principle of Optics
Biological Microscope
Eyepiece
WF10X/18mm
Objective
Achromatic Objective 4X, 10X, 40X, 100x(Oil)
Nosepiece
Backward Quadruple Nosepiece
Stage
Double Layer Mechanical Stage 132X142mm/ 75X40mm
Focusing
Coaxial Coarse & Fine Adjustment
Condenser
Abbe NA 1.20 with Iris Diaphram and Filter
Illumination
1W S-LED illumination, Brightness Adjustable
Transport Package
Strong Carton with Polyfoam Protection
Trademark
BestScope
Origin
China
Production Capacity
1000 Sets Per Month
Product Description
IntroductionBS-2020 series microscopes are economic, practical and easy to operate. These microscopes adopt LED illumination, which saves energy, has long working life and also comfortable for observation. These microscopes are widely used in educational, academic, agricultural and study field. With a microscope adapter, a digital camera (or digital eyepiece) can be plug into the trinocular tube or the eyepiece tube. Built-in rechargeable battery is optional for outdoors operation or places that power supply is not stable. Feature1. Comfortable operation with updated and ergonomic design;2. LED light illumination, save energy and long working life;
3. Compact and flexible, ideally suited for desktop, laboratory worktable. ApplicationBS-2020 series microscopes are ideally suited for school biological education and medical analyses area to observe all kinds of slides. They can be widely used in clinics, hospitals, schools, academic labs and scientific research department. Specification
| Item | Specification | BS-2020M | BS-2020B | BS-2020T |
| Viewing Head | Monocular Head, Inclined at 30°, 360° Rotatable | * | | |
| Seidentopf Binocular Head, Inclined at 30°, 360° Rotatable, Interpupilary Distance 48-75mm | | * | | |
| Seidentopf Trinocular Head, Inclined at 30°, 360° Rotatable, Interpupilary Distance 55-75mm | | | * | |
| Eyepiece | WF10×/18mm | * | * | * |
| WF16×/11mm | ○ | ○ | ○ | |
| WF25×/8mm | ○ | ○ | ○ | |
| Objective | Achromatic Objective 4×, 10×, 40×, 100×(Oil) | * | * | * |
| Achromatic Objective 20×, 60× | ○ | ○ | ○ | |
| Nosepiece | Backward Quadruple Nosepiece | * | * | * |
| Stage | Double Layer Mechanical Stage 132×142mm/ 75×40mm | * | * | * |
| Focusing | Coaxial Coarse & Fine Adjustment, Fine Division 0.004mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.4mm per Rotation, Moving Range 24mm | * | * | * |
| Condenser | Abbe NA 1.20 with Iris Diaphram and Filter | * | * | * |
| Illumination | 1W S-LED illumination, Brightness Adjustable | * | * | * |
| Halogen Lamp 6V/ 20W, Brightness Adjustable | ○ | ○ | ○ | |
| Immersion oil | 5ml Immersion oil | * | * | * |
| Optional Accessories | Phase Contrast Kit | ○ | ○ | ○ |
| Dark Field Attachment | ○ | ○ | ○ | |
| Polarization Attachment | ○ | ○ | ○ | |
| Rechargeable battery | ○ | ○ | ○ | |
| Package | 1pc/carton, 39.5cm*26.5cm*50cm, 7kg | * | * | * |
Sample Images
