Ut0002 Sidewall Fire Sprinkler with UL Approval for Fire Fighting
| US$0.80-2.30 | 500 Pieces (MOQ) |
Basic Info.
Model NO.
Ut0002
Closed Fire Sprinkler System
Wet Fire Sprinkler System
Nozzle Flow Coefficient
80
Bulb
3mm or 5mm
Finish
Brass and Chrome Plated and White Plated Available
Temperature Rating
57/68/79/93/141degree
Nominal Thread Size
1/2” NPT or 1/2” BSPT
Certificates
UL,ISO and CCC
Transport Package
Carton
Trademark
Utec
Origin
China
HS Code
8424901000
Production Capacity
5000000pieces/Year
Product Description
DESCRIPTION Sidewall sprinkler is designed for use in automatic sprinkler systems designed in accordance with standard installation (NFPA13).The temperature response is standard response 5mm glass bulb and fast response 3mm glass bulb. The sprinklers come with compact design. available in different finishes and temperature ratings.
The sprinklers body is made of brass forging copper alloy (DZR). The spring seat consists of a spring Belleville washer coated on both side with a Teflon tape.
Pendent and conventional and sidewall sprinklers are installed with adjustable or non-adjustable escutcheon plates. These are intended to be installed finished ceilings. Escutcheon plate adjustment provides convenience in pendent and conventional sprinkler installation in case of areas with finished ceiling or walls.
TECHNICAL SPECIFICATION
| Style | Pendent, Upright, Sidewall, Conventional and Recessed Pendent,Recessed Sidewall, Recessed Conventional |
| K Factor gpm/(psi)½( L/min(bar)½ ) | 5.6 (80) |
| Nominal Thread Size | 1/2" NPT OR 1/2" BSPT |
| Max. Working Pressure | 175 PSI (12BAR) |
| Factory Test Pressure | 500 PSI (35BAR) |
| Min. Operating Pressure | 7 PSI (0.5 BAR) |
| Finish | Brass and Chrome Plated and White Plated Available |
Material Specification
| Deflector | Brass UNS-28000 |
| Bulb | Glass with Glycerin Solution JOB G5 or Day-impex-937 for Ut0001, Ut0003, Ut0005, Ut0007 JOB F3 or Day-impex-941 for Ut0002, Ut0004, Ut0006 |
| Load Screw | Brass UNS-28000 |
| Seal | Brass UNS-28000 |
| Frame | Brass UNS-28000 |
| Seal Washer | Belleville Washer coated on both sides with Teflon Tape |
| Bulb Nominal Diameter | Standard Response 5.0mm, Quick Response 3.0mm |
Packaging & Delivery
Packaging Details: carton packing: 42cmx22cmx14.5cm and 100 pieces in one carton packing. 6.5KG weight each one carton.
Delivery Detail: 100,000 pieces can be ready for delivery within 40 days.
Different shipping way are available.
Products
| SIN | Response type | Sprinkler Style | Temp. Rating F (C) |
| Ut0001 | SR | Sidewall | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0002 | QR | Sidewall | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0003 | SR | Upright | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0004 | QR | Upright | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0005 | SR | Pendent | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0006 | QR | Pendent | 135(57) 155(68) 175(79) 200(93) 286(141) |
| Ut0007 | SR | Conventional | 135(57) 155(68) 175(79) 200(93) 286(141) |
