2. Vmc1160s CNC Machine Tools with 13kw Main Motor

Product Description

Company Profile - Suji Intelligent Equipment Jiangsu Co., Ltd
Company Profile
Suji Intelligent Equipment Jiangsu Co., Ltd
Suji Intelligent Equipment Jiangsu Co., Ltd was established in 2018 and is located in the Jiangsu Shuyang National Economic Development Zone. We are a comprehensive science and technology enterprise engaged in the development, production, research and development, sales, and service of CNC machine tools, including vertical machining centers.
With a professional technical team dedicated to CNC machine tool manufacturing and service, we have years of experience in research and development and manufacturing. Our company boasts advanced processing and testing equipment, scientific management, and exquisite technical force, allowing us to provide cost-effective machine tools that maximize the value of your investment.
Major Products
Vertical machining center series
Horizontal machining center series
Gantry machining center series
Flat rail CNC lathe
Inclined rail CNC lathe
Our machine tools are known for their high speed, high rigidity, high performance, and high efficiency. They are the preferred choice for industries such as communication, consumer electronics, medical, LED, automotive, aerospace, and more.
We have a strong research and development ability and have obtained ISO9001 quality system certification. Quality and service are the foundation of our enterprise. Our business philosophy is to create value for customers, opportunities for employees, and benefits for society. We are committed to providing high-quality pre-sale, sale, and after-sales service, along with professional technical support.
We are dedicated to meeting the needs of our customers and markets. We look forward to developing together with our partners and creating a better tomorrow.
Product Description
Product Description
Detailed Photos
Product Parameters

S/Model	Unit	VMC640S	VMC850S	VMC855S	VMC1160S	VMC1370S	VMC-1580S
Machining Range
X axis travel	mm	600	800	800	1100	1300	1500
Y axis travel	mm	400	500	550	600	700	800
Z axis travel	mm	450	500	550	600	700	700
Spindle nose to table	mm	150-600	150-650	120-670	120-720	110-810	130-830
Spindle center to column	mm	470	545	595	645	750	810
Workbench size
Table Dimension	mm	700X420	900X500	1000X550	1200X600	1400X700	1800X800
T-slot Dimension	mm	3X14X120	3X18X130	5X18X90	5X18X100	7X18×100	22X5X140
Max Load	kg	250	500	500	800	1000	1500
Spindle
Taper		BT40	BT40	BT40	BT40	BT40/BT50	BT40/BT50
Max Speed	rpm	Direct 12000			8000-1000rpm
Infeed System
G00 fast infeed(Axis X/Y/Z)	m/min	48/48/48	48/48/48	48/48/48	36/36/36	36/36/36	36/36/36
G01 cutting infeed	m/min	1-10000	1-10000	1-10000	1-10000	1-10000	1-10000
Tool Magazine
Type	type	Disc	Disc	Disc	Disc	Disc	Disc
Capacity	unit	24	24	24	24	24	24
Machine Dimension
Length	mm	1800	2300	2500	3200	3600	3850
Width	mm	2400	2800	2000	2400	3300	3100
Height	mm	2300	2700	2200	2800	2900	2900
Weight	kgs	4600	4600	4800	7500	10500	12000

Suji Intelligent Equipment Jiangsu Co., Ltd offers a precision lathe CNC machining center. This machine tool is perfect for grinding, boring, drilling, and milling. It is a versatile and high-quality option for metal turning and gear hobbing.
Introducing the Precision Lathe CNC Machining Center from Suji Intelligent Equipment Jiangsu Co., Ltd. This versatile machine tool combines precision lathe capabilities with CNC machining for efficient and accurate operations. It is suitable for grinding, boring, drilling, and milling tasks. With its advanced features and high-quality construction, it is a reliable choice for all your machining needs.
