Mayair Industrial CNC Machine Smoke Air Filter Purifier Electrostatic Oil Mist Collector

Product Description

Product Description
SELECTION OF THE NUMBER OF INDUSTRIAL ELECTROSTATIC OIL MIST PURIFIER UNITS IN THE EAC-IE/SI SERIES COMBINATION (CHOOSING THE NUMBER OF MODULAR UNITS)
SELECTION METHOD FOR ELECTROSTATIC OIL MIST PURIFIERS
This device can purify suspended oil mist and smoke in machining workshops, improving the air quality in the workshop. To select the appropriate number of units, follow these steps:
Step 1. Air Change Rate (R) Typically, the industrial sector uses ten air changes per hour (Refer the table for empirical parameters) Xα
Step 2. Required Air Volume to Be Processed (Q) V R Q Volume of the room (working space) (m³) Air change rate per hour V×R
Step 3. Calculation Method for Selecting Number of Air Purifier Units U Q Xα α U Q÷Xα Required air volume to be processed Unit processing air volume under the required purification efficiency Required purification efficiency Required number of air purifier units (rounded to a decimal)

GENERAL OCCASIONS	FREQUENCY / TIMES
Conditions with a low smoke volume	6~8
Conditions with a moderate smoke volume	8~10
Conditions with a high smoke concentration	10~16

STANDALONE ELECTROSTATIC OIL MIST PURIFIER EAC-SI SINGLE-STAGE / EAC-SI2 DUAL-STAGE
PRODUCT FEATURES
Reduced Maintenance Costs: The equipment design includes oil mist pre-filters that are highly efficient and a large-capacity electrostatic dust collection area. It can capture and filter three to four times more oil mist than oil mist purifiers of the same volume. This results in an increased operational lifespan of the equipment and a significant reduction in maintenance frequency.
Improved Eficiency in Oil Mist Purification: Operators can easily regulate the air volume of the equipment up to 1600m3/h by adjusting the motor speed, resulting in better oil mist purification efficiency.
No More Filter Replacements Required: The electrostatic dust collection unit is easy to clean and thus eliminates the need for expensive filter replacements.
Reduced Downtime for Maintenance: The equipment is equipped with maintenance doors, allowing quick electrostatic component maintenance.Product Parameters
ELECTROSTATIC OIL MIST PURIFIER DATA SHEET

MODEL	AIR VOLUME (m³/h)	WEIGHT (kg)	POWER OF FAN (kw)	NUMBER OF IONIC CELLS	NUMBER OF ACCESS DOORS MAINTENANCE
EAC01-SI-10	1600-2000	91	0.56	1	1
EAC01-S12-10	1600-2000	137	0.59	2	2
EAC01-S1-20	3200-4000	105	1.3	2	1
EAC01-S12-20	3200-4000	250	1.36	4	2

CONCEPTUAL DIAGRAM FOR ENVIRONMENTAL PURIFICATION SCHEME IN WORKSHOP

CONCEPTUAL DIAGRAM OF A CENTRALIZED MACHINE TOOL OIL MIST PURIFICATION SYSTEM

Working Principle
The pre-filter captures large particles, such as hair and debris, in the dirty air drawn through the fan. Small particles pass through the pre-filter mesh and continue moving forward with the airflow. After passing through the ionization section, particles as small as 0.01 micrometers are ionized and acquire a positive charge.
Simultaneously, high-intensity electric pulses generate shockwaves that cause irreversible damage to bacteria attached to the particles or induce denaturation and separation of proteins within the bacteria. This results in a sterilization effect.
After passing through the dust collection section, the particles are captured and adsorbed by the negatively charged plates. Subsequently, the activated carbon filter or chemical filter adsorbs odors or other harmful gases. Finally, the purified air exits the system.
Application
This product is ideal for purifying dust-producing processes located at a single point with uneven distribution. It has high filtration efficiency and meets indoor emission standards.
FAQ
Q1. Are you true manufacture or Trade company?
A:We are professional manufacture in China, located in Nanjing, more than 16 years.
Our head factory in Nanjing, Wuxi also have one factory for Horizontal dust collector.
Q2. What strengths you have?
A: Excellent technology and produce line, professional sales and R&D department.
Q3. Would it be possible for us to visit your factory?
A: Welcome to visit our any one factory at any working time.
Q4. Will your company supply samples?
A: We can supply sample, but the customers have to pay the sample cost and the courier cost at first. Sample cost can be refunded if you place formal orders in the future.
Q5. How can we get the quotation of Oil mist collector ?
Pls check and confirm the application and airflow.
Q6. What is your product range?
A: Our products include filter cartridge, sintered filter, oil mist collector, dust collector equipment and other accessories.
