FAW 4X2 10cbm Arm Roll Garbage Bin Cleaner Compressed Garbage Truck
Basic Info.
Model NO.
CSC
Type
Roll Off
Certification
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume
1000-3000L
Emission Standard
Euro 2
Transmission Type
Manual
Payload
20T
Fuel
Diesel
Drive Wheel
4×2
Brand
FAW
Models
Medium
Usage
Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
Condition
New
Item Name
Garbage Can Cleaning Truck Capacity
Wheelbase
3800mm
Volumes
3cbm, 5cbm, 8cbm, 10cbm, 12cbm,
Color
as Your Demand
Transport Package
Bulk or Wax
Specification
8000x2500x3500 mm
Trademark
CS
Origin
Suizhou, Hubei
HS Code
870590
Production Capacity
5000 Pieces / Year
Packaging & Delivery
Package Size
8000.00cm * 2500.00cm * 3550.00cm
Package Gross Weight
9000.000kg
Product Description
Product Description Arm Roll Garbage Bin Cleaner (Side-Lifting Garbage Truck):Mechanism: Equipped with a hydraulically operated arm that can lift and tip bins to empty the contents into the truck's collection hopper. Efficiency: Allows for the emptying of bins without the need for manual labor, increasing the speed and efficiency of waste collection. Versatility: Can handle a variety of binsizes and types, making it suitable for different environments such as streets, commercial areas, and residential complexes. Hygiene: Reduces the exposure of waste collectors to potentially hazardous waste, improving working conditions. Operation: The arm can be controlled from the truck's cab, allowing the operator to safely and accurately empty bins. Detailed Photos
Product Parameters
| Cabin | Driving type 4x2 | |
| H5 Cabin with two seats,with A/C. Right Hand Driven. 70° hydraulically tillable to the front as attached photo for ref. | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8000x2500x3500 |
| Wheel base (mm) | 4200 | |
| Wheel track (front/rear) (mm) | 1980/1860 | |
| Approach/Departure angle(°) | 24/15 | |
| Weight in KGS | Tare Weight | 8000 |
| Loading Capacity | 10000 | |
| Front axles loading capacity | 1×6000 | |
| Rear axles loading capacity | 1x12000 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Brand | YUCHAI |
| Model | YC6J220-33 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 220 HP | |
| Emission standard | Euro 3 | |
| Gearbox | DC6J65TC, 6 forwards &1 reverse | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Steering Gear | ZF steering, hydraulic steering with power assistance | |
| Fuel tank (L) | 300 L | |
| Tire | 10.00R20 tires with one spare, totally 7 pcs. | |
| Swing arm system with cargo box | ||
| l Garbage cargo box :10CBM , Carbon steel material , underground type or aboveground type can be optional. | ||
| l PTO motivated hydraulic system, two hydraulic cylinders with lifting arm and two hydraulic cylinders with landing leg | ||
| l Swing arm maximum pivot angle 145 ; hoisting time 30s ; Unloading time 50s. | ||
