Roller Mesh Plywood Papel Veneer Drying Dryer Machine for Wood Based Panel Machine

Product Description

Roller Mesh Plywood Papel veneer drying dryer machine for woodworking machinery
Veneer dryer machine belongs to veneer machine, or also can say belongs to plywood machine. Because whatever you produce veneer or plywood, usually the veneer dryer machine is necessary and important for the production process.
The function of veneer dryer machine for drying veneer humidity, the peeled veneer come from veneer lathe, its humiidty is high, 40%-70% according to different wood species. Such high humidity is not suitable for making the wooden products.
So the veneer dryer machine will through high heating temperature remove veneer moisture, and the end veneer humidity will be suitable for making end product.
Veneer dryer machine mainly includes three types, one is roller dryer, one is mesh dryer, the last one is press dryer. different them, has different advantages.
Today we mainly introduce the veneer mesh dryer for you.
Actually veneer mesh dryer is very similar with veneer roller dryer, they can be very big set, and cover much more land, also they can be customized to be different width, floors, and sections, to satisfy different drying capacity. So what is the difference between these two types dryer machine? the biggest difference is their convey way are different. The veneer mesh dryer's conveyor way by stainless steel wire, the veneer roller dryer's conveyor way by rollers.
You can see the first picture is stainless steel wire, it is for veneer mesh dryer
The second picture is rollers, for veneer roller dryer
Some clients prefer to mesh dryer, some clients like roller dryer
They have their own features, so we will offer the type according to clients requires.

Name	2 Decks veneer dryer machine	3 layers veneer dryer machine	4 layers veneer dryer machine
Dryer type	mesh wire	mesh wire	mesh wire
Width	2800mm	3500mm	4500mm
Heating section	12	12	12
Cooling section	2	2	2
Heating motor	7.5kw	11kw	15kw
Veneer thickness	1-3mm	1-3mm	1-3mm
End humidity	5-14%	5-14%	5-14%
Weight	64000kgs	88000kgs	110000kgs

For our veneer drying machine, With good designed and mature structure, make sure the dryer machine can drying veneer good, except reach the setted required humidity, at the same time, still keep veneer surface smooth and complete.

For our veneer dryer machine, all material and spare parts, we choose and use good type, one set veneer mesh dryer is big, and it includes many different kinds of accessories. Each part even small part, it has different choice, and the common type with good type, its cost are different, thus it will cause the whole dryer machine cost different.
For our drying machine, we not use common type, only choose the better type, for make sure the whole drying machine is good and strong and high quality. You can use very well and many years.

Until now we have exported many big sets veneer dryer to different foreign clients, and when they start use our dryer, they all very satisfied. That's why we insist use good material to make sure our dryer good.

MINGHUNG MACHINE,was founded in 1998, located in Linyi city, Shandong Province China, commit to provide the full sets of Plywood production line. Minghung Wood machinery, Minghung trade, Jianzhong trade, Hungyou Intelligent Equipment Industry Research, belong to us.
With more than 20 years production experience, and adhere to continuous innovation and improvement, with specialized R&D center, obtained a number of research and development patents, with experienced technians and engineers, and professional sales team and after-sales team, We have beome one China's high-end plywood machinery manufacturing enterprise.
We can provide Veneer production line, Veneer drying line, Core veneer composing line, Plywood assembly line, Veneer patching machine, Glue machine, Cold press machine, Hot press machine, Film faced hot press machine, Plywood edge trimming machine, Sanding machine, Plywood panel turnover machine, Lift table and so on for you.
Our principle is "Make customers satisfied and Create greater value for customers".
<1> How long of your machine warranty?
2 years for main parts.
<2> The production time?
60 days
<3> Payment terms:
T/T. 30% deposit, 70% before delivery.
<4> Will you help me solve when i meet problem about machine?
We will at the fist time reply you and help you solve.
<5> Will you engineer come to install machine?
Yes, when machine soon reach your factory, our engineer will go to your factory.
Welcome contact us for veneer dryer machine, or other veneer plywood macihne.
