Solar Grid Tie Charger Single/Dual Triple 50Hz/60Hz Frequency 1A DC/AC Inverter Limiter

Product Description

Product Description
Customized products can consult online customer service!
Product advantages 1. Using advanced dual-CPU microcontroller intelligent control technology, featuring high reliability and low failure rate; 2.pure sine wave output, with strong load carrying capacity and wide application range; 3. complete protection functions (overload protection, internal over-temperature protection, output short-circuit protection, input undervoltage protection, input overvoltage protection, etc.), greatly improving the reliability of the product; 4. small size and light weight, with internal CPU centralized control and SMD technology, making the size very small and light weight; 5. intelligent control of the heat sink fan,using the CPU to control the working state of the heat sink fan, greatly extending the service life of the fan, and saving powerand improving efficiency; 6. Small working noise, high efficiency Parameters

Model			PA-300W
Input	Rated voltage		12V	24V	48V
	Voltage range		10-15.5VDC	20-31VDC	40-62VDC
	No load current draw		0.5A	0.25A	0.15A
	Efficiency		> 90%
Output	AC voltage		100/110/120VAC or 220/230/240VAC
	Continuous power		500W
	Surge power		1000W
	Waveform		pure sine wave form
	Frequency		50Hz or 60Hz
	USB Output		5V,1A
	AC regulation		≤3%
Protection	Low voltage alarm		10.5±0.5V	21.0±1V	42.0±1V
	Low voltage shut down		10.0±0.5V	20.0±1V	40.0±1V
	Over voltage shut down		15.5±0.5V	31.0±1V	62.0±1V
	Short circuit		Shut off output automatically
	Over load		Shut off output automatically
	Over thermal		Shut off output automatically
Environment	Working temperature		-10ºC and +50ºC
	Working humidity		20%~90%RH
	Storage temperature		-30ºC ~ +70ºC
Package	Single Data	Machine Size mm		242*142*65
		Net weigh KG		1.0
		Gross weight KG		1.2
		Packing size mm		295*160*115
	Total Data	Package quantity pcs		10
		Weight KG		12.76
		Outer packing size mm		630*310*350
		Outer packing Volume m³		0.0629
Note: The above data is for reference only and is subject to the actual product.

When placing order, please provide the following technical parameters 1. kV rated voltage: 2. rated voltage; 3. Combination of three levels, accurate phase and accurate; 4, rated output, and the corresponding accurate level (VA).
