880/1040mm Multi-Layer PVC ASA Glazed Roof Tile Machine

Product Description

1.The Market Reason for 3 Layer PVC Composite Roof Tile
During the mass production of 2 layers PVC roof tile, more and more waste side material produced which will make pollution when discarded improperly, but now a new economic solution is made in which these side or trim material will be firstly crashed and milled,and then feeded to a third PVC powder extruder to produce the recycled layer or middle layer in a 3 layer roof tile production line.Actually this kind of solution is very popular, because it can save costs and protect the environment, and most important of all, it almost have nothing negative on the quality of the roof tile, and then 3 layer PVC roof tile become popular in the market.
2.Machine list

No.	Machine	Qty.
1	Screw loader (for SJZ 80/156 with push device)	1set
2	SJZ 80/156 conical twin-screw extruder (PVC powder)	1set
3	Vacuum loader and drying hopper (SJ 50/30)	1set
4	SJ50/30 single screw extruder (ASA pellet)	1set
5	Screw loader (for SJZ 65/132 with push device)	1set
6	SJZ 65/132 conical twin-screw extruder ( recycled PVC)	1set
7	Extrusion die	1set
8	Adaptor	1set
9	Embossing roller	1set
10	Forming machine	1set
11	Cutter machine with dust collector	1set
12	Stacker	1set
11	Oven (Ridge tile)	1set
12	Screw loader for 80 and 65 extruder respectively	2sets
13	Mixer unit(500/1000, 300/600)	2sets
14	Crusher(for recycling side material)	1set
15	Pulverizer(for recycling side material)	1set

3.Features tile products and machine
Machine Advantage

No.	Machine	Technical specifications
1	SJZ80/156 conical twin-screw extruder	Extruder with double screw feeder Screw vacuum with double vacuum Five-zone heating Reliable electrical components Bimetallic treatment screw
2	SJZ65/132 conical twin-screw extruder	Extruder with double screw feeder Screw vacuum with double vacuum Four-zone heating Reliable electrical components Bimetallic treatment screw
3	SJ50/30 single screw co-extruder	Bimetallic treatment screw
4	Extrusion mould	Clothes hanger tunnel Mirror polishing Cr coating Three dimensional flow simulation software design
5	Embossing roller	Hard chromium plating on surface Design of spiral flow passage in roller Motor separately drive to ensure consistent speed
6	Forming machine	The module is a one-time die-casting molding Module material LY12 high quality aluminum Advanced machining center,one-time clamping of the module Four cylinder lift more stable
7	Cutter	Special positioning device to ensure the cutting accuracy Downside the knife cutting mode running smoothly PLC HMI operation
8	Oven	Double door double control, upside and downside at the same time operation Flat open the door, the insulation effect is good and to prevent burns Accurate temperature control is in 1 degree

Plastic roof tile Advantages: 1.Excellent heavy load performance. 2.Save cost for investor, production line service life for more than 20 years. 3.Fire resistance, not spontaneous combustion. 4.Lightweight and easy for transportation. 5.Excellent waterproofing performance ,water resistance when heavy rains and the rainy season 6.Anti corrosion: resistance to acid and alkali, quite applicable for roofing of workshop for chemical products. 7.Collision resistance and low temperature resistance.
8.Low thermal expansivity. 9.Good sound and heat insulation. 10.Environmental friendly and energy conservation. 11.Easy to install, packing and transport. 12.Longlasting color more than 15 years. 13.Eco environment-friendly,can be recycled by plastic crusher and pulverizer to be reused.
4. After-sales service
1 Technical documents All the symbols on the equipments should be in English. Seller is responsible to provide general layout plan, electric plan, installation direction, and manual book in English to Buyer on time. 2. Quantity and quality guarantee a. Quantity/Quality Discrepancy to destination port during transportation: In case of quality/quantity discrepancy to destination port in transportation, customer should file claim within 30 days after the arrival of the goods at port of destination. Insurance company and shipping company will be responsible for any discrepancy of the goods caused by shipping company and other transportation organization and/or post office. b. Guarantee period and after-sales services: 12 months since date of bill of lading During this guarantee period, ACEMIEN will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, ACEMIEN will provide the buyer spare parts at cost price. c. Long-term service: ACEMIEN will charge the buyer cost price of spare parts beyond one year and provide long-term technical guide.
5.Contact details
Manager: Kevin Lu
Jiangsu Acemien Machinery CO.,LTD
Website: acemien.en.made-in-china.com
Address:No.2, Changhong Road, Modren Agriculture Demonstration Park, Zhangjiagang City, JiangSu Province, China 215600
