Factory 5kw 10kw 20kw off Grid Solar System Photovoltaic Home Energy Storage System

Product Description

Product DescriptionFactory 5kw 10kw 20kw Off Grid Solar System Photovoltaic Home Energy Storage System
Our system configuration

5KW/6KW/8KW/10KW Off Grid Solar System Configuration
Parts	Specification	Quantity
		5KW	6KW	8KW	10KW
Solar panel	410W Mono Half cell	12 pcs	14 pcs	20 pcs	24 pcs
Off grid inverter	110~120V or 220V~240V AC 50/60Hz, Built-in MPPT	5KW 1 pcs	6KW 1 pcs	8KW 1 pcs	10KW 1 pcs
Wifi	optional	1 pcs	1 pcs	1 pcs	1 pcs
LiFePO4 Battery	Powerwall/Rack-mounted, 48V 5KWH/10KWH, optional	1 pcs	1 pcs	1 pcs	1 pcs
PV combiner box	2 input 1 output	1 pcs	2 pcs	3 pcs	4 pcs
Mounting Bracket	Roof or Ground Installation	1 set	1 set	1 set	1 set
PV cables	4mm²	100 meters	100 meters	200 meters	200 meters
MC4 connector	Male + Female	5 pairs	10 pairs	10 pairs	15 pairs
Installation tools	optional	1 set	1 set	1 set	1 set

Product ParametersSOLAR PANEL
-25 years warranty
-All Black Mono type
-High-efficiency M10 solar cells
-Half-cut cell technology
-Less shadow lossOFF-GRID INVERTER
-3 years warranty
-Integrated MPPT charge controller
-Work with battery or without battery
-Maximum PV input voltage up to 450VDC
-Configurable grid or solar input priority
-Support parallel operation for capacity expansion up to 30kW
-Optional WIFI/ GPRS remote monitoringLIFEPO4 BATTERY (Powerwall type)
-10 years warranty
-8000 cycles work life
-5kwh and 10kwh capacity optional
-Support parallel connection up to 16 pcs
-Built-in battery management system
-Wide compatible with inverters MOUNTING BRACKET SYSTEM
(Including all parts)
-15 years warranty
-Roof or ground installation optional
-Aluminum alloy, galvanized steel material optional
-Resistance to 60m/s wind speed and 1.4kN/m² snow pressure Detailed PhotosOur packaging
Our projects
Recommend Products
Our factory
ANHUI GP NEW ENERGY CO., LTD
We, Anhui GP New Energy Co., Ltd (Great Pack) focus on LiFePO4, Li-polymer, Li-ion rechargeable batteries, solar energy battery, are the leading Lifepo4 battery supplier in China, who committed to the R&D, design, and innovation of lithium batteries to supply Green & Clean energy to our daily modern lives!
Our team has over 8 years of experience in the lithium battery field, and supply One Stop Power Solution suggestions to help you to save time & capital and achieve advanced technologies and excellent OEM/ODM service.
Quality is life, Great Pack is committed to supplying high-quality batteries and the best service to our clients all over the world. Our battery has passed CE, UN38.3, RoHS, MSDS certificates. We are committed to becoming a leading solution provider to go global in the Solar lithium battery industry.
Our workshop
Our Certifications
Won the authoritative certification from the strict requirements, so that consumers can reset assured to buy and use
FAQ
Q1: Can the product be shipped to my area?
A1: We export to most countries/regions (Centre/South America, EMEA, SEA, SSA, AU). We will check and confirm for you after you provide the region.
Q2: What about the lead time?
A2: 10 Working days for 200kw requirements.
Q3: How can I make a payment?
A3: 100% TT, or we can accept 30% TT in advance and 70% TT upon goods being ready before shipment.
