High-Speed ABA Film Blown Machine Energy-Saving Blown Film Equipment

Product Description

Product Description
The ABA film blowing machine adopt SACM 645 screw,and the screw L/D ratio adopt 32:1.All machine adopt super high speed screw with force feeding.ABA film blowing machine adopt three-layer co-extrusion technology,with recycled materials used in the middle layer to improve production efficiency and achieve resource recycling. Product Parameters

Model	50/50-1200	55/55-1400
Width of the film	500-1000mm	800-1200mm
Thickness of the film	HDPE:0.008-0.08mm LDPE:0.02-0.15mm
Output	40-160kg/h	40-200kg/h
	According to different width, thickness of film,die size and raw material characteristics to change
Raw material	HDPE/MDPE/LDPE/LLDPE/CACO3/RECYCLING
Diameter of screw	Φ50/50	Φ55/55
L/D ratio of screw	32:1 (With force feeding)
Gear box	173# *2	180# *2
Main motor	18.5kw*2	22kw*2
Die diameter	Φ100/250mm	Φ150/ 250mm

Detailed Photos
Company Profile
Certifications

Packaging & Shipping
FAQ
Q: How about after-sales service? How long is the machine warranty?
A: We guarantee lifetime after-sale service once you bought our machine, you can call us or send us any questions about the machine.
Q: How long is your delivery time and how many machines can you produce per month?
A: Normally our film blowing machine will be delivered within 30 days after 100% testing .
Q: How long can your machine work continuously?
A: We advice the machine working 24 hours a day without stopping, which not only increases production but also saves energy.
Q: Does your factory need agents? What are the thresholds?
A: We need to recruit agents, welcome to inquire for more details.
Q: Where is your factory? How can I visit there?
A: We are located in Ningjin County, Hebei Province, one of China's plastic production and processing distribution centers. It only takes one hour by high-speed rail from Beijing and 2-3 hours by plane from Shanghai and Guangzhou.Warmly welcome domestic and foreign customers to visit us.
