Rust Removal Metal Paint Pulse Laser Cleaner Laser Cleaning Robot

Product Description

Product Description
Equipment features 1. The laser beam can be precisely positioned during the cleaning process, removing only the area that needs to be treated, without damaging the material surface.
2. A variety of cleaning modes can be selected, easy to operate.
3. Laser cleaning does not require any chemical cleaning agents or other pollutants, avoiding environmental pollution.
4.The laser cleaning machine utilizes the high energy density of the laser beam to quickly and thoroughly remove dirt, rust, paint, oxidized layers and other contaminants. Compared with traditional cleaning methods, laser cleaning machine is faster.

Product Parameters
Technical parameter

Model	CH-1500C	CH-2000C
Number of axis	6 Axis
Payload	12kg
Active radius	1500mm	2000mm
Robot weight	176kg	198kg
Repetitive positioning accuracy	±0.05
Maximum operating range
1 Axis S	±180°
2 Axis L	-125°~ +90°
3 Axis U	-86°~ +202°
4 Axis R	±170°
5 Axis B	-150°~ +116°
6 Axis T	±360°
Maximum operating speed
1 Axis S	200°/s	145°/s
2 Axis L	185°/s	115°/s
3 Axis U	155°/s	150°/s
4 Axis R	265°/s	265°/s
5 Axis B	215°/s	215°/s
6 Axis T	260°/s	260°/s
Protection grade	IP54 (Wrist IP65)
Installation method	Ground,arm hanging,tilting,upside down
Installation environment	Temperature 0-45ºC, humidity 20-80% RH (no frost), vibration acceleration below 4.9m/s (0.5G), altitutde below 1000m Others (no igniting and corrosive gas, liquid, no splashing water,little oil, dust, far away from electromagnetic source)
