Aeon Laser Redline CO2 Laser Cutting Machine Super Elite Nova 1490 1610 100W 130W 150W with Ruida Lightburn Software for Windows Mac Linux Acrylic Cutter
| US$2,000.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Nova14 Super
Application
Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Textile Machinery, Food Machinery, Aerospace Industry, Automotive Industry, Shoemaking Industry, Woodwork Industry, Advertising Industry
Cooling System
Water Cooling
Technical Class
Pulse Laser
Applicable Material
Nonmetal
Structure Type
All-in One Compact Body
Laser Classification
Gaseous Laser
Laser Technology
Laser Vapor Cutting
Engraving Speed
2000mm/S
Laser Tube
Glass Tube 80-150W& RF30/60W
Software
Ruida or Lightburn
Safety Level
Class 1
Linear Guide
Fully Sealed Dust Proof Design
Acceleration
5g
Trademark
Aeon Laser
Origin
China
HS Code
8456110090
Production Capacity
4800/Year
Product Description
Aeon Laser Super Nova14 is a professional co2 laser engraving and cutting machine. The working area is 900*1400mm. Super Nova14 offers the Metal RF & Glass DC in one machine. Nova14 Super's engraving speed is as fast as MIRA series machines. Also can go 2000mm/sec, the acceleration speed is 5G, has the fastest speed in its class.The structure of the Nova14 super is very strong, which makes it more steady. The machine equipped with honeycomb and blade worktable and with model 5200 chiller, makes it possible to install 100W or even 130W laser tube. The Z-axis now increased to 200mm, so it can fit in higher products. The air assists system got pressure gauge and regulator to give the users option to add a more powerful compressor to cut thicker materials. The front and back material pass-through door makes it possible to cut long materials| Nova Super14 | |
| Working Area | 900*1400mm |
| Machine Size | 1600*1210*1025mm |
| Machine Weight | 550kg |
| Work Table | Honeycomb + Blade |
| Laser power | 80W-150W CO2 Glass Tube & 30/60w RF tube |
| Eletric Up&Down | 200mm (7 7/8") Adjustable |
| Air Assist | 105W Built-In Air Pump |
| Blower | Elite10 330W Built-In Exhaust Fan, Elite14,16 550W Built-in Exhaust Fan |
| Cooling | Elite10 Built-in 5000 Water Chiller, Elite14,16 Built-in 5200 Chiller |
| Input Voltage | 220V AC 50Hz/110V AC 60Hz |
| Engraving Speed | 2000mm/s(47 1/4"/S) |
| Cutting Speed | 800mm/s (31 1/2 "/S) |
| Cutting Thickness | 0-30mm(depends on different materials ) |
| Max Acceleration Speed | 5G |
| Laser Optical Control | 0-100% Set by software |
| Minimum Engraving Size | Minimum Font Size 1.0mm x 1.0mm(English Letter) 2.0mm*2.0mm(Chinese Charactor) |
| Max Scanning Precision | 1000DPI |
| Locating Precision | <=0.01 |
| Red Dot Positioning | Yes |
| Built-in WIFI | Optional |
| Auto Focus | Integrated Autofocus |
| Engraving Software | RDWorks/LightBurn |
| Graphic Format Supported | AI/PDF/SC/DXF/HPGL/PLT/RD/SCPRO2/SVG/LBRN/BMP/JPG/JPEG/PNG/GIF/TIF/TIFF/TGA |
| Compatible Software | CorelDraw/Photoshop/AutoCAD/All kinds of Embroidery Software |
