roll to sheet cutting machine for Printed PVC /Paper/PET/Fabric

Product Description

Product Description
Roll to sheet cutting machine for Printed paper / pvc/ fabric printed label sheeting machine , paper cutting machine \ https://youtu.be/fjPYG5C_7UM printed paper sheet cutting machine https://youtu.be/2APFNGypG3E Printed fabric roll to sheet cutting machine https://youtu.be/zULKzvewh2s automatic PVC film roll to sheet cutting machinehttps://youtu.be/Q91CTo3wJMk Video : https://youtu.be/ZF8X4zPPlVM 600mm sparkle material cutting to sheethttps://youtu.be/Cqm_Ah-FCkw 500mm green pvc roll to sheet cutter sheet cutting machine 1. Microcomputer control , setting length of cutting Feature: This machine adopts man-machine interface control and PLC system with pneumatic pushing device, half cutting off after multi-cut, full cutting off after one-cut, special sizing cutting , five different cutting length can be set , different cutting quantity and circulation time also can be set, to improve cutting efficiency . High precision, low loss, easy operation. Application: cutting for conductive fabric, foam , diffuser , reflector film , double-sided adhesive tape, nickel plate, PET, PC,PE insulation paper, and all kinds of adhesive tapes . advantage as below : Servo motor control ---more precision then Stepper motor control , so we already Eliminated stepper motor machineBrand name use : Delta or Mitsubishi PLC ----- use famous brand MITSUBISHI which you will easily maintenence in your local placeTouch screen operation and switch operation together Machine body ----- 20 mm thickness steel wall , it is very solid that to make sure machine stable when running and the steel wall is whole steel sheet , not connected together .PULLING ROLLER ---- Thick PU rubber coated and won't scratch the materialGuiding roller ------- Aluminum shaft be polished and hard anodized , very smooth and never harm materialCutting Blade ----SKD11 material to make sure the cutter use very very long time and cutting material perfect edge at cutting part unwinding air-shaft ------------------- 3 inch air-shaft Safety cover ---- have safety cover at cutting blade , and sensor at it , no cover will not work , to protect the operator safety Large size roll to sheet cutting machine use Safety Light Curtain to protect operator Below is optional parts : machine slitting cutter -------------- is round cutter is high speed stainless steel material , it made in Korea company , can use long time ( no grinding ofen ) Rectification system ----------- unwinding part can turn left and right when tracing eye working and find the unwinding material is not tidy , it is same function as a slitting machine unwinding part Photocell for mark searching , ----------- used for printed material precision cutting , the Brand name use is SUNX under Panasonic electrical static eliminator -----------------to remove orneutralizing static electricity from the paper , film etc material High Precision Roll to Sheet Cutting Machinery Functional Characteristics: This machine employs servo motor to feed material, import PLC touch screen operation to set any length, quantity,speed and finish singleness cutting , equipped with automatic unwinding system and air shaft,which will be easy to load and unload."Purpose: It is applicable for the cutting of Paper,aluminum foil, copper foil, PET, PC, PVC, PCB, FPC, Lithium battery film, flannelette,metal foil, PVC film, insulation sheet, Mylar, foam, industrial tape, electronic tape and various inch setting electronic materials. Technical Data ModelMax Feeding WidthMain Engineer PowerSpeed SizeWeight Precision unwinding diameter unwinding core Voltage mmKWT/MIN MMKGmm mm DP-360CQ36011101150*1000*1230350±0.05600/10003 inch380V 50HZDP-500CQ5001.51101250*1090*1230420±0.05600/10003 inch380V 50HZDP-600CQ6002.21001300*1200*1250500±0.05600/10003 inch380V 50HZDP-800CQ8003801400*1400*1250800±0.05600/10003 inch380V 50HZDP-1000CQ10003751950*1800*13501000±0.10600/10003 inch380V 50HZDP-1400CFQ14004.5602050x2150x14002000±0.10600/10003 inch380V 50HZ Video links about these machines :roll to sheet cutting machine video 500mmhttp://youtu.be/hlw7YjXucf0 https://youtu.be/TddZP9BJos4 (360 https://youtu.be/hlw7YjXucf0 http://youtu.be/StpI-7gi1io filter paper slit and cut sheet cutting machine https://youtu.be/ZF8X4zPPlVM 600mm sparkle material cutting to sheethttps://youtu.be/Cqm_Ah-FCkw 500mm green pvc roll to sheet cutter http://youtu.be/FKYZw7SKQZs?list=UUKzn2_YUjZc_nkjjFRC07NQ (500/watch?v=wbJhPKudBYA&list=UUKzn2_YUjZc_nkjjFRC07NQ&index=13 ( 800http://youtu.be/Pp5_tqE7QR4?list=UUKzn2_YUjZc_nkjjFRC07NQ (800 mm ) http://youtu.be/x_A6leioBek?list=UUKzn2_YUjZc_nkjjFRC07NQ ( 1000 mm ) http://youtu.be/KYlL-HxKAGM 550 kiss cut and through cutting machine https://youtu.be/XvDXNd42zOk printting paper with photocell sheet cutting machine https://youtu.be/zULKzvewh2s 500 https://youtu.be/4l9zWCdr1TI hot roll to sheet cutting machine ( heating the blade and cutting thick PVC/PET) https://youtu.be/2APFNGypG3E printed paper sheet cutting machine
