Fully Automatic Plywood Machine High-Frequency Heating, Two-Dimensional Pressure, Used for Splicing, Wood Strip Edge Sealing, Automatic Wood Board Machine

Product Description

1,Application :
It mainly apply to laminated wood, particle board,door panel jointing, and solid wood, door pocket, door line banding, or other wooden block gluing etc.
1. High Timber Out turn : 5%-10% more on average compared to the general clamp carrier
2. High Efficiency : 1-3 mins to finish one board , especially processing in winter much more significant
3. Energy Saving :15-30 kw/h power consumption for 1 cbm board jointing
4. Low Labor Cost :feeding & discharging device of belt-conveyer , adding palletizing and gluing system for option to get more efficient as well
5. Heavy Frame : Using large-scale machine tool to ensure its verticality
6. Easy Operation: Touch screen HML, with a built-in operation instruction which including installation, operation, repair, maintenance etc.
7. Safety :Adding high sensitive spark protection circuit and make separated cabinet for HF parts
8. Good components :assorting Taiwan pneumatic tools mostly
9. The thinnest board of jointing is 6 mm at least, 80 mm max thickness
2,High frequency ComposerThis production line of heavy duty high frequency board jointing machine can compose a single length of 6 meters board.

	CGPB-28P	CGPB-46P	CGPB-65P	CGPB-83P	CGPB-91P
Working bench size	2500*1300mm	2500*1300mm	2500*1300mm	2600*1300mm	2300*1300cm
Thickness of board	10-50mm	10-80mm	10-150mm	10-180mm	15-200mm
Upper pressure	9T	13T	13T	13T	21T
Back pressure	19T	33T	52T	70T	70T
Outer dimension(L*W*H)	8700*2300*2300mm	8700*2350*2300mm	8700*2350*2300mm	8800*2350*2300mm	8800*4400*2300mm
Weight	3.5t	5.5t	6.5t	7t	9t
Feeding mode	Auto	Auto	Auto	Auto	Auto

3,Machine detail show:
4, Machine characteristics:
5, Sample Show
End product show:
8, Company Information
Qingdao Xinlihui Machinery Co., Ltd is one of the large-scale woodworking machinery manufacturer in China. The company is located in Wangtai town.
Our company is a comprehensive enterprise which is specialized in research and development, design, manufacturing, sale and service. With advanced production equipment and professional technical staff of research and development, and management. Which is formed a unique management model and the standardization of production process.
The leading products of woodworking products are CNC router, panel saw series, sanding machine series, woodworking drill machine, Pur wrapping machine, paper sticking machine, vacuum laminating machine, edge banding machine, computer engraving machine and the other series and over sixty standards. With the scientific management, unique technology, and innovative products to meet customer demands. Our products get a very high reputation from our customers at home and abroad. Our products are sold across the country and to Russia, Ukraine, Middle-East, South Africa, Southeast Asia, Central Europe and the other countries and areas. We have earned the trust of customers and our product process is in the leading level among the same industry of domestic. It creates a famous brand called "XINLIHUI" and our products sell well both at home and abroad. It is the most trusted brand to our customers.
We would like to work a new win-win development with the insight colleagues and we welcome all the new and old friends to visit our company and crest a brilliant tomorrow together.
