Heavy Duty Universal Milling Machine with Swivel Head and Table
Basic Info.
Model NO.
UM1460
Type
Tool Milling Machine
Object
Tool
Structure
Lifts
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Integral
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Table
1700X400
Transport Package
Wooden Case
Specification
XL8132
Trademark
Allway
Origin
China
HS Code
8459590
Production Capacity
1000PCS/Year
Product Description
Heavy duty universal milling machine UM1460 with table swivel table Specifications: Logical, clearly arranged gearshift for speed change Hardened and polished guide ways guarantees top accuracy Setting of the required feed speed by potentiometer on the control panel Finely graduated feeds in all axis, driven by servo motor Universal mill head system 'Huron' adjusts to various angles Complete with rapid feed in x-, y- and z-axis to reduce downtime Optimal adjustments of spindle speed and feed allow for economic machining of various materials| Specifications | Unit | UM1460 |
| Table size | mm | 1700×400 |
| Table travel (X/Y/Z) | mm | 1300/450/650 |
| T-slots(NO./width/pitch) | mm | 3/18/100 |
| Table feed speed X axis | mm/min | 25~800 |
| Table feed speed Y axis | mm/min | 25~800 |
| Table feed speed Z axis | mm/min | 8~267 |
| Spindle taper | 7:24 IS050 (H) 7:24 IS050 (V) | |
| Arm travel | mm | 700 |
| Distance from vertical spindle to table | mm | 200-850 |
| Distance from horizontal spindle to table | mm | 0-500 |
| Distance from spindle to arm | mm | 200 |
| Spindle speed range | r.p.m | 50-1520 (V) 60-1850 (H) |
| Spindle speed steps | steps | 12 |
| Main motor power | Kw | 5.5 (H) 5.5 (V) |
| AC servo feed motor torque | N.m | 12 |
| Overall size | mm | 2245×2100×2000 |
| Net weight | kg | 3700 |
Standard accessories : Mill chuck set
Draw bar
Mill arbors
Worktable swivel ±50 degree
Reduction sleeve
Coolant device
Coolant tray
Automatic central lubrication
Foundation bolts
Tools Optional accessories : Machine vice 160mm
Machine vice 200mm
3-Axis Digital readout
Universal Dividing Head F11-160A
Rotary table TSL300
58 pcs Clamping kits
Spindle protection
Worktable protection
Slotting head
