Universal Knee Type Turret Milling Machine (X6336WA)
| US$3,300.00-3,600.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X6336WA X6332WA
Structure
Ram
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Overall Welding Tooth
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Table Size
1630*360mm
Long Travel(mm)
1000mm
Cross Travel(mm)
300mm
Vertical Travel(mm)
405mm
RAM Travel(mm)
500mm
Transport Package
Plywood Case
Specification
2850kgs
Trademark
HOTON
Origin
China
HS Code
8459590000
Production Capacity
10 PCS/Month
Product Description
VERTICAL AND HORIZONTAL TURRET MILLING MACHINE X6336WA
Hardened guideway
Taiwan high speed turret milling head
X.Y & Z axis auto feeding
Milling Machine has added 45 degree swivel table
Large torgue and strong power, fast moving is 2000mm/min
SPECIFICATIONS:
| SPECIFICATIONS | X6336WA |
| Spindle taper | ISO40V ISO50 H |
| Arm travel | 500 |
| Spindle speed range(r.p.m) | 68-7200 V 60-1800 H |
| Table size | 1630*360 |
| Table travel | 1000*300*405 |
| Main motor(kw) | 4.0 H 3.7/2 (V) |
| Distance from vertical spindle to table surface(mm) | 135-485 |
| Distance from horizontal spindle to table surface(mm) | 0-350 |
| Overall dimensions(mm) | 2000×2000×2250 |
| N.W/G.W (kg) | 2650/2850 |
| Contact Us: |
| Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
