Fully Automatic LED Lamp Cup Molding Equipment Plastic Injection Machines
| US$45,000.00-60,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
TC-1600-3R
Type
Tube Head Injection
Structure
Vertical
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Screw Diameter (mm)
40--42
Maximum Injection Pressure (Kg/Cm2)
2268--1835
Clamping Force (Ton)
160
Opening Force (Ton)
13
Opening Stroke (mm)
300
Total Capacitance (Kw)
13.8
Machine Specification(M)
2.9*2.35*3.6
Weight of Machine (Kg)
8500
Transport Package
Plywood Case Pcking
Specification
160T/220T
Trademark
TianCheng
Origin
Dongguan Guangdong
HS Code
8477101090
Production Capacity
20000 Sets/Year
Packaging & Delivery
Package Size
290.00cm * 235.00cm * 360.00cm
Package Gross Weight
8500.000kg
Product Description
Welcome to Dongguan Tiancheng Machinery Co., LtdWith our customizable options, we can tailor the machine to your specific requirements. To get started, please provide us with the following information:
1.The size of the mold
2.The product pictures
3.The product Drawing/Specifications
4.How many PCS of products are made in one mold
5.How many gram per product
6.The material to be used for the products
Product Description
Detailed Photos
Product Parameters
| Brand Name | Tiancheng | Style | VERTICAL | |
| Condition | New | Model NO. | TC-1600-3R | |
| Screw Diameter (MM) | 40--42 | Max.Hydraulic Pressure(Kg/cm3) | 140 | |
| Maximum injection Pressure (Kg/cm2) | 2268--1835 | Pump Output (L/min) | 68 | |
| Theoretical Shot Volume (Cm3) | 226--254 | Oil Tank Capacity (L) | 600 | |
| Maximum Shot Weight (G/oz) | 202/7.2--226/8.0 | Cooling Water Consumption(L/H) | 800-1000 | |
| Injection Rate (Cm3/sec) | 220-260 | Electric Power (KW) | 22 | |
| Screw Speed (R/Min) | 0--240 | Total capacitance (KW) | 13.8 | |
| Screw Rate (MM) | 220 | Total Wattage (KW) | / | |
| Nozzle Retraction Stroke (MM) | 330 | Machine Specification(M) | 2.9*2.35*3.6 | |
| Clamping Force (Ton) | 160 | Weight of Machine (KG) | 8500 | |
| Opening Force (Ton) | 13 | Plastic Processed | PP, ABS, FRPP/PVC, PE, ABS/PP, PE/PP | |
| Platen Size (MM) | 1384 | After-sales Service Provided | Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support | |
| Distance Between Tie-Bere (MM) | / | After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service | |
| minimum Mold Thickness (MM) | 300/400 | Warranty | 1 year | |
| Opening Stroke (MM) | 300 | Applicable Industries | Manufacturing Plant, Construction works , Energy & Mining, Other | |
| Max-Distance opening mold (MM) | 600/700 | |||
| Max.Mold Size | 550*500 | |||
| Ejector Force (Ton) | 4.6 | |||
| Ejector Stoke (MM) | / |
Packaging & Shipping
Certifications
After Sales Service
FAQ
| Q1: Are you a trading company or a manufacturer? |
| A1: Factory we are, all the machine are made by ourselves. Besides, you can get the customize service with your requirements |
| Q2: What's your warranty for the machine? |
| A2: One Year Warranty(all the machine parts can be replaced within one year free of charge, not including the manmade broke), life-time maintenance. |
| Q3: What's your Delivery Time? |
| A3: Usually it is 3-5 days if the machine is in stock; If not, the delivery time is 10-25 days according to your required quantity and our busy season. |
| Q4: Why choose TianCheng Machinery Co., Ltd.? |
| A4: "Tiancheng Machinery, we sincere, you succeed!" are the driving force for our company to moving forwards. We will devote every efforts to do the best level machine and service. |
